Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED PFM CLAS A 9 W/2700 K B22d DIM | B22d | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/2700 K E27 DIM | E27 | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/2700 K E27 FIL DIM | E27 | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/4000 K B22d DIM | B22d | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/4000 K E27 DIM | E27 | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 12 W/2700 K E27 | E27 | 12 W | 220…240 V | 15000 h | 1521 lm | 100 W | 320 ° | Yes |
| LED PFM CLAS A 12 W/2700 K E27 | E27 | 12 W | 220…240 V | 15000 h | 1521 lm | 100 W | 320 ° | Yes |
| Nominal wattage | 13 W |
| Construction wattage | 13.00 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 100 W |
| Nominal current | 60 mA |
| Type of current | AC |
| Operating frequency | 50…60 Hz |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.90 |
| Luminous flux | 1521 lm |
| Nominal useful luminous flux 90° | 1521 lm |
| Luminous efficacy | 117 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Warm White |
| Color temperature | 2700 K |
| Color rendering index Ra | ≥80 |
| Light color | 827 |
| Standard deviation of color matching | ≤6 sdcm |
| Rated LLMF at 6,000 h | 0.80 |
| Beam angle | 220 ° |
| Warm-up time (60 %) | ‹ 1.00 s |
| Starting time | < 0.5 s |
| Overall length | 120.00 mm |
| Diameter | 60.00 mm |
| Maximum diameter | 60 mm |
| Product weight | 70.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.90 |
| Base (standard designation) | E27 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | Yes |
| Energy efficiency class | E 1) |
| Energy consumption | 13.00 kWh/1000h |
| Photobiological safety group acc. to EN62778 | RG1 |
1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)
| Order reference | LPCLADIM 13W/82 |
| Light source cap-type (or other electric interface) | E27 |
| Correlated colour temperature type | SINGLE_VALUE |
| Length | 120.00 mm |
| Height | 60.00 mm |
| Width | 60.00 mm |
| EPREL ID | 1403219 |
| Model number | AC24703 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075532403 | Folding box 1 |
62 mm x 62 mm x 120 mm | 87.00 g | 0.46 dm³ |
| 4058075532410 | Shipping box 10 |
323 mm x 134 mm x 133 mm | 1014.00 g | 5.76 dm³ |
