Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| HALOLINE 100 W 230 V R7S | R7s | 100 W | 230 V | 1000 h | 1250 lm | Yes |
| HALOLINE 100 W 110…130 V R7S | R7s | 100 W | 110…130 V | 1000 h | 1540 lm | Yes |
| HALOLINE 150 W 230 V R7S | R7s | 150 W | 230 V | 1000 h | 2000 lm | Yes |
| HALOLINE 150 W 230 V R7S | R7s | 150 W | 230 V | 1000 h | 2000 lm | Yes |
| HALOLINE 150 W 220…240 V R7S | R7s | 150 W | 220…240 V | 1000 h | 2000 lm | Yes |
| HALOLINE 150 W 110…130 V R7S | R7s | 150 W | 110…130 V | 1000 h | 2400 lm | Yes |
| HALOLINE 200 W 120 V R7S | R7s | 200 W | 230 V | 1000 h | 2800 lm | Yes |
| HALOLINE 300 W 220…240 V R7S | R7s | 300 W | 220…240 V | 1000 h | 4400 lm | Yes |
| HALOLINE 300 W 230 V R7S | R7s | 300 W | 230 V | 1000 h | 4400 lm | Yes |
| HALOLINE 300 W 110…130 V R7S-15 | R7s | 300 W | 110…130 V | 1000 h | 6000 lm | Yes |
| HALOLINE 500 W 230 V R7S | R7s | 500 W | 230 V | 1000 h | 7700 lm | Yes |
| HALOLINE 500 W 220…240 V R7S | R7s | 500 W | 220…240 V | 1000 h | 7700 lm | Yes |
| HALOLINE 5000 W/HBM OFR | R7s | 500 W | 110…130 V | 1000 h | 9500 lm | Yes |
| HALOLINE 750 W 230 V R7S | R7s | 750 W | 230 V | 2000 h | 15000 lm | Yes |
| HALOLINE 1000 W 230 V R7S | R7s | 1000.00 W | 230 V | 2000 h | 21580 lm | Yes |
| HALOLINE 1500 W 230 V R7S | R7s | 1500.00 W | 230 V | 2000 h | 31000 lm | Yes |
| Nominal wattage | 750 W |
| Construction wattage | 750.00 W |
| Nominal voltage | 230 V |
| Luminous flux | 15000 lm |
| Luminous efficacy | 20 lm/W |
| Light color (designation) | Warm White |
| Color temperature | 3000 K |
| Color rendering index Ra | 100 |
| Light color | 1030 |
| UV protection | No |
| Starting time | 0 s |
| Overall length | 189.00 mm |
| Diameter | 12 mm |
| Product weight | 13.00 g |
| Base (standard designation) | R7s |
| Mercury-free | Yes |
| Design / version | Tube |
| Product remark | Fuse protection with indicated values recommended acc. to IEC60357, EN60357, For outdoor applications and operation in damp locations special approved fixtures are required |
| Dimmable | Yes |
| Burning position | p15 |
| Energy efficiency class | G |
| Energy consumption | 750.00 kWh/1000h |
| ILCOS | HDG-750-230-R7s-191,1 |
| Order reference | 64560 750W 230V |
| Lighting technology used | OTHER |
| Non-directional or directional | NDLS |
| Mains or non-mains | MLS |
| Light source cap-type (or other electric interface) | R7s |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Claim of equivalent power | No |
| Length | 189.00 mm |
| Height | 12 mm |
| Width | 12 mm |
| Chromaticity coordinate x | 0.444 |
| Chromaticity coordinate y | 0.406 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 714424,1635408 |
| Model number | AC35326,AC54067 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300004167 | Folding box 1 |
26 mm x 26 mm x 238 mm | 21.00 g | 0.16 dm³ |
| 4050300223933 | Shipping box 12 |
247 mm x 114 mm x 91 mm | 340.00 g | 2.56 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4050300004167 | 8327702 | 4739688 | 3720032 | 940306076 |
