Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| HALOPIN OVEN 40 W 230 V G9 | G9 | 40 W | 230 V | 2000 h | 490 lm | Yes |
| Nominal wattage | 40 W |
| Construction wattage | 40.00 W |
| Nominal voltage | 230 V |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Power factor λ | 1.00 |
| Luminous flux | 490 lm |
| Luminous efficacy | 12 lm/W |
| Light color (designation) | Warm White |
| Color temperature | 2700 K |
| Color rendering index Ra | 100 |
| Light color | 1027 |
| Starting time | 0 s |
| Overall length | 43.00 mm |
| Light center length (LCL) | 22,0 mm |
| Diameter | 14.00 mm |
| Product weight | 2.8 g |
| Ambient temperature range | -20…+40 °C |
| Base (standard designation) | G9 |
| Mercury-free | Yes |
| Design / version | Tube |
| Dimmable | Yes 1) |
| Burning position | Any |
1) Check dimmer compatibility at ledvance.com/compatibility
| Energy efficiency class | G |
| Energy consumption | 40.00 kWh/1000h |
| Standards | CE, EAC, UKCA |
| ILCOS | HSGST/C/UB-40-230-G9-22 |
| Order reference | 66740 OVEN |
| Temperature range at storage | -20…+80 °C |
| Lighting technology used | OTHER |
| Non-directional or directional | NDLS |
| Mains or non-mains | MLS |
| Light source cap-type (or other electric interface) | G9 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 43.00 mm |
| Height | 14.00 mm |
| Width | 14.00 mm |
| Chromaticity coordinate x | 0.460 |
| Chromaticity coordinate y | 0.411 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 931185,2194498 |
| Model number | AC35348,AC68761 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4008321703576 | Folding box 1 |
70 mm x 23 mm x 25 mm | 6.20 g | 0.04 dm³ |
| 4008321703583 | Shipping box 20 |
144 mm x 55 mm x 118 mm | 118.00 g | 0.93 dm³ |
| 4099854491887 | Shipping box 20 |
134 mm x 75 mm x 99 mm | 160.00 g | 0.99 dm³ |
| 4099854491894 | Shipping box 120 |
247 mm x 154 mm x 224 mm | 1150.00 g | 8.52 dm³ |
| EAN | SEG number | STK number | EFO number |
|---|---|---|---|
| 4008321703576 | 8326512 | 4730125 | 3710274 |
