Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED ANTI-BACTERIAL CLAS A 60 8.5 W/2700 K B22d | B22d | 8.5 W | 220…240 V | 15000 h | 806 lm | 60 W | 200 ° | No |
| LED ANTI-BACTERIAL CLAS A 60 8.5 W/4000 K B22d | B22d | 8.5 W | 220…240 V | 15000 h | 806 lm | 60 W | 200 ° | No |
| LED ANTI-BACTERIAL CLAS A 60 8.5 W/6500 K B22d | B22d | 8.5 W | 220…240 V | 15000 h | 806 lm | 60 W | 200 ° | No |
| Nominal wattage | 8.5 W |
| Construction wattage | 8.50 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 60 W |
| Nominal current | 50 mA |
| Type of current | AC |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Power factor λ | > 0.50 |
| Luminous flux | 806 lm |
| Nominal useful luminous flux 90° | 806 lm |
| Luminous efficacy | 94 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Cool White |
| Color temperature | 4000 K |
| Color rendering index Ra | ≥80 |
| Light color | 840 |
| Standard deviation of color matching | ≤6 sdcm |
| Rated LLMF at 6,000 h | 0.80 |
| Beam angle | 200 ° |
| Warm-up time (60 %) | 0.50 s |
| Starting time | < 0.5 s |
| Overall length | 112.00 mm |
| Diameter | 60.00 mm |
| Maximum diameter | 60 mm |
| Product weight | 29.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.90 |
| Base (standard designation) | B22d |
| Mercury content | 0.0 mg |
| Dimmable | No |
| Energy efficiency class | F |
| Energy consumption | 9.00 kWh/1000h |
| Standards | CB, EMC, RoHS |
| Photobiological safety group acc. to EN62778 | RG0 |
| Order reference | LSCLA60B 8,5W/8 |
| Temperature range at storage | -20…+80 °C |
| Light source cap-type (or other electric interface) | B22d |
| Correlated colour temperature type | SINGLE_VALUE |
| Length | 112.00 mm |
| Height | 60.00 mm |
| Width | 60.00 mm |
| R9 Colour rendering index | 0.00 |
| EPREL ID | 523311 |
| Model number | AC31153 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075700710 | Folding box 1 |
62 mm x 62 mm x 117 mm | 38.00 g | 0.45 dm³ |
| 4058075700727 | Shipping box 10 |
318 mm x 132 mm x 130 mm | 494.00 g | 5.46 dm³ |
