Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED VALUE STICK 7 W/2700 K B15d GEN1 | B15d | 7 W | 220…240 V | 15000 h | 700 lm | 60 W | 200 ° | No |
| LED VALUE STICK 7 W/2700 K E14 GEN1 | E14 | 7 W | 220…240 V | 15000 h | 700 lm | 60 W | 200 ° | No |
| LED VALUE STICK 7 W/2700 K E14 GEN4 | E14 | 7 W | 220…240 V | 15000 h | 700 lm | 200 ° | No | |
| LED VALUE STICK 7 W/4000 K E14 GEN4 | E14 | 7 W | 220…240 V | 15000 h | 750 lm | 200 ° | No | |
| LED VALUE STICK 7 W/6500 K B15d GEN1 | B15d | 7 W | 220…240 V | 15000 h | 750 lm | 60 W | 200 ° | No |
| LED VALUE STICK 7 W/6500 K E14 GEN1 | E14 | 7 W | 220…240 V | 15000 h | 750 lm | 60 W | 200 ° | No |
| LED VALUE STICK 7 W/6500 K E14 GEN4 | E14 | 7 W | 220…240 V | 15000 h | 750 lm | 200 ° | No | |
| LED VALUE STICK 12 W/2700 K E27 | E27 | 12 W | 100…240 V | 15000 h | 1300 lm | |||
| LED VALUE STICK 12 W/4000 K E27 | E27 | 12 W | 100…240 V | 15000 h | 1350 lm | |||
| LED VALUE STICK 12 W/6500 K E27 | E27 | 12 W | 100…240 V | 15000 h | 1350 lm |
| Nominal wattage | 7 W |
| Construction wattage | 7.00 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 60 W |
| Nominal current | 55 mA |
| Type of current | AC |
| Operating frequency | 50…60 Hz |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.50 |
| Luminous flux | 700 lm |
| Nominal useful luminous flux 90° | 700 lm |
| Luminous efficacy | 100 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Warm White |
| Color temperature | 2700 K |
| Color rendering index Ra | 80 |
| Light color | 827 |
| Standard deviation of color matching | ≤6 sdcm |
| Rated LLMF at 6,000 h | 0.80 |
| Beam angle | 200 ° |
| Warm-up time (60 %) | ‹ 0.50 s |
| Starting time | < 0.5 s |
| Overall length | 112.00 mm |
| Diameter | 40.00 mm |
| Maximum diameter | 40 mm |
| Product weight | 31.00 g |
| Ambient temperature range | -20…+35 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.80 |
| Base (standard designation) | B15d |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | No |
| Energy efficiency class | A+ 1) |
| Energy consumption | 7.00 kWh/1000h |
| Photobiological safety group acc. to EN62778 | RG0 |
1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)
| Order reference | LVSTICK 7W/827 |
| Light source cap-type (or other electric interface) | B15d |
| Length | 112.00 mm |
| Height | 40.00 mm |
| Width | 40.00 mm |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075126688 | Folding box 1 |
43 mm x 43 mm x 117 mm | 53.00 g | 0.21 dm³ |
| 4058075126695 | Shipping box 10 |
218 mm x 92 mm x 132 mm | 510.00 g | 2.65 dm³ |
