Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED ECO PAR16 36 ° 2.5 W/3000 K GU10 | GU10 | 2.5 W | 220…240 V | 8000 h | 230 lm | 35 W | 36 ° | No |
| LED ECO PAR16 36 ° 2.5 W/6500 K GU10 | GU10 | 2.5 W | 220…240 V | 8000 h | 230 lm | 35 W | 36 ° | No |
| LED ECO PAR16 36 ° 4 W/3000 K GU10 | GU10 | 4 W | 220…240 V | 8000 h | 350 lm | 50 W | 36 ° | No |
| LED ECO PAR 16 120 ° 4.5 W/3000 K GU10 | GU10 | 4.5 W | 220…240 V | 15000 h | 350 lm | 35 W | 120 ° | No |
| LED ECO PAR 16 120 ° 4.5 W/4000 K GU10 | GU10 | 4.5 W | 220…240 V | 15000 h | 350 lm | 35 W | 120 ° | No |
| LED ECO PAR16 36 ° 4 W/4000 K GU10 | GU10 | 4 W | 220…240 V | 8000 h | 350 lm | 50 W | 36 ° | No |
| LED ECO PAR 16 120 ° 4.5 W/6500 K GU10 | GU10 | 4.5 W | 220…240 V | 15000 h | 350 lm | 35 W | 120 ° | No |
| LED ECO PAR 16 36 ° 5 W/3000 K GU10 | GU10 | 5 W | 220…240 V | 15000 h | 400 lm | 50 W | 36 ° | No |
| LED ECO PAR 16 36 ° 5 W/4000 K GU10 | GU10 | 5 W | 220…240 V | 15000 h | 400 lm | 50 W | 36 ° | No |
| LED ECO PAR16 36 ° 5 W/6500 K GU10 | GU10 | 5 W | 220…240 V | 15000 h | 400 lm | 50 W | 36 ° | No |
| LED ECO PAR 16 36 ° 5 W/6500 K GU10 | GU10 | 5 W | 220…240 V | 15000 h | 400 lm | 50 W | 36 ° | No |
| Nominal wattage | 2.5 W |
| Construction wattage | 2.50 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 35 W |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Power factor λ | 0.40 |
| Luminous intensity | 600 cd |
| Luminous flux | 230 lm |
| Nominal useful luminous flux 90° | 195 lm |
| Luminous efficacy | 92 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Warm White |
| Color temperature | 3000 K |
| Color rendering index Ra | 80 |
| Light color | 830 |
| Standard deviation of color matching | ≤6 sdcm |
| Rated peak intensity | 600 cd |
| Beam angle | 36 ° |
| Warm-up time (60 %) | ‹ 0.50 s |
| Starting time | < 0.5 s |
| Overall length | 52.00 mm |
| Diameter | 50.00 mm |
| Maximum diameter | 50 mm |
| Product weight | 30.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.90 |
| Base (standard designation) | GU10 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | No |
| Energy efficiency class | A+ 1) |
| Energy consumption | 2.50 kWh/1000h |
1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)
| Order reference | LEPAR163536 2,5 |
| Light source cap-type (or other electric interface) | GU10 |
| Length | 52.00 mm |
| Height | 50.00 mm |
| Width | 50.00 mm |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075204515 | Folding box 1 |
49 mm x 49 mm x 62 mm | 37.00 g | 0.15 dm³ |
| 4058075204522 | Shipping box 10 |
255 mm x 107 mm x 72 mm | 420.00 g | 1.96 dm³ |
