Choose your product version
| Product description | Nominal wattage | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|
| LED VALUE HE BATTEN 3.40 W 3000 K 300 mm | 3.40 W | 120 ° | 340 lm | No |
| LED VALUE HE BATTEN 3.40 W 4000 K 300 mm | 3.40 W | 120 ° | 340 lm | No |
| LED VALUE HE BATTEN 3.40 W 6500 K 300 mm | 3.40 W | 120 ° | 340 lm | No |
| LED VALUE HE BATTEN 6.50 W 3000 K 600 mm | 6.50 W | 120 ° | 585 lm | No |
| LED VALUE HE BATTEN 6.50 W 4000 K 600 mm | 6.50 W | 120 ° | 650 lm | No |
| LED VALUE HE BATTEN 6.50 W 6500 K 600 mm | 6.50 W | 120 ° | 650 lm | No |
| LED VALUE HE BATTEN 9.60 W 3000 K 900 mm | 9.60 W | 120 ° | 864 lm | No |
| LED VALUE HE BATTEN 9.60 W 4000 K 900 mm | 9.60 W | 120 ° | 960 lm | No |
| LED VALUE HE BATTEN 9.60 W 6500 K 900 mm | 9.60 W | 120 ° | 960 lm | No |
| LED VALUE HE BATTEN 13.00 W 3000 K 1200 mm | 13.00 W | 120 ° | 1170 lm | No |
| LED VALUE HE BATTEN 13.00 W 4000 K 1200 mm | 13.00 W | 120 ° | 1300 lm | No |
| LED VALUE HE BATTEN 13.00 W 6500 K 1200 mm | 13.00 W | 120 ° | 1300 lm | No |
| Nominal wattage | 3.40 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 17.000 mA |
| Power factor λ | 0.90 |
| Protection class | II |
| Luminous flux | 340 lm |
| Luminous efficacy | 90 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | 80 |
| Standard deviation of color matching | ≤5 sdcm |
| Beam angle | 120 ° |
| Length | 325.00 mm |
| Height | 32.50 mm |
| Width | 22.20 mm |
| Product weight | 49.00 g |
| Product color | White |
| Housing color | White |
| Body material | Polycarbonate (PC) |
| Cover material | Polycarbonate (PC) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+35 °C |
| Temperature range at storage | -20…+70 °C |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Replaceable light source (EPREL) | Not replaceable |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075414266 | Folding box 1 |
390 mm x 23 mm x 34 mm | 84.00 g | 0.30 dm³ |
| 4058075414273 | Shipping box 24 |
405 mm x 150 mm x 150 mm | 2342.00 g | 9.11 dm³ |
