Choose your product version
| Nominal wattage | 4.50 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 60.000 mA |
| Inrush current | 25 A |
| Inrush current time Th50 | < 1500 µs |
| Max. number of luminaires per miniature circuit breaker C10 | - |
| Power factor λ | > 0.5 |
| Total harmonic distortion | < 20 % |
| Protection class | II |
| Operating mode | External LED driver |
| Luminous flux | 240 lm |
| Total luminous flux of contained light sources | 480 lm |
| Luminous efficacy | 56 lm/W |
| Color temperature | 3000…6500 K |
| Light color (designation) | Tunable White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | < 6 sdcm |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 110 ° |
| Diameter | 85.00 mm |
| Height | 23.00 mm |
| Product weight | 60.00 g |
| Cable length | 150 mm |
| Product color | White |
| Housing color | White |
| Body material | Plastic |
| Cover material | Polystyrene (PS) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+70 °C |
| Type of connection | Screw terminal |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | Yes |
| Type of dimming | WiFi |
| Mounting type | Recessed |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Mounting diameter | 72,0 mm |
| Mounting depth | 35,0 mm |
| LED module replaceable | Not replaceable |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 25000 h |
| Number of switching cycles | 15000 |
| Type of emergency operation test | None |
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075573239 | Folding box 1 |
97 mm x 97 mm x 57 mm | 83.00 g | 0.54 dm³ |
| 4058075573246 | Shipping box 6 |
202 mm x 104 mm x 186 mm | 721.00 g | 3.91 dm³ |
| 4058075643017 | Shipping box 36 |
422 mm x 335 mm x 209 mm | 4759.00 g | 29.55 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075573239 | 941506220 |
