Choose your product version
| Nominal wattage | 22.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Inrush current | ≤30 A |
| Inrush current time Th50 | 1000 µs |
| Power factor λ | > 0.70 |
| Total harmonic distortion | < 20 % |
| Protection class | I |
| Operating mode | External LED driver |
| Luminous flux | 1800 lm |
| Total luminous flux of contained light sources | 2500 lm |
| Luminous efficacy | 81 lm/W |
| Color temperature | 3000…6500 K |
| Reference control setting of contained light source (Kelvin) | 3000 K 1) |
| Light color (designation) | Tunable White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | < 6 sdcm |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 110 ° |
1) Performing a reset will restore the default values set by the manufacturer
| Diameter | 400.00 mm |
| Height | 40.00 mm |
| Product weight | 1270.00 g |
| Product color | White |
| Housing color | White |
| Body material | Aluminum |
| Cover material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+70 °C |
| Type of connection | Screw terminal |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | Yes |
| Type of dimming | WiFi |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| LED module replaceable | Not replaceable |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 25000 h |
| Number of switching cycles | 15000 |
| Integrated test switch | No |
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075572935 | Folding box 1 |
48 mm x 440 mm x 444 mm | 1448.00 g | 9.38 dm³ |
| 4058075572942 | Shipping box 5 |
459 mm x 268 mm x 472 mm | 8084.00 g | 58.06 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075572935 | 941390270 |
