Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| CFL SQUARE 16 W/827 GR8 | GR8 | 16 W | 103 V | 10000 h | 1050 lm | No |
| CFL SQUARE 16 W/835 GR8 | GR8 | 16 W | 103 V | 10000 h | 1050 lm | No |
| CFL SQUARE 28 W/827 GR8 | GR8 | 28 W | 108 V | 10000 h | 1900 lm | No |
| CFL SQUARE 28 W/835 GR8 | GR8 | 28 W | 108 V | 10000 h | 1900 lm | No |
| Nominal wattage | 16 W |
| Construction wattage | 16.70 W |
| Nominal voltage | 103 V |
| Nominal current | 0.2 A |
| Luminous flux | 1050 lm |
| Luminous efficacy | 63 lm/W |
| Light color (designation) | LUMILUX INTERNA |
| Color temperature | 2700 K |
| Color rendering index Ra | ≥80 |
| Light color | 827 |
| Rated LLMF at 2,000 h | 0.85 |
| Rated LLMF at 4,000 h | 0.78 |
| Rated LLMF at 6,000 h | 0.76 |
| Rated LLMF at 8,000 h | 0.75 |
| Overall length | 136.00 mm |
| Diameter | 13.00 mm |
| Product weight | 64.4 g |
| Ambient temperature range | -5…+40 °C |
| Service life | 6000 h |
| Rated lamp survival factor at 2,000 h | 0.99 |
| Rated lamp survival factor at 4,000 h | 0.94 |
| Rated lamp survival factor at 6,000 h | 0.84 |
| Rated lamp survival factor at 8,000 h | 0.68 |
| Lifespan B50 | 10000 h |
| Base (standard designation) | GR8 |
| Mercury content | 3.0 mg |
| Design / version | OSRAM CFL SQUARE® 2-Pin for CCG |
| Dimmable | No |
| Energy efficiency class | G |
| Energy consumption | 17.00 kWh/1000h |
| ILCOS | FSS-16/827-I-GR8 |
| Order reference | CFL SQUARE 16W/ |
| Lighting technology used | CFLNI |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | GR8 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 136.00 mm 1) |
| Height | 27.5 mm |
| Width | 141 mm |
| Chromaticity coordinate x | 0,463 |
| Chromaticity coordinate y | 0,420 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546532 |
| Model number | AC34306 |
1) Maximum
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300816852 | Folding box 1 |
29 mm x 152 mm x 152 mm | 118.00 g | 0.67 dm³ |
| 4050300816869 | Shipping box 20 |
326 mm x 322 mm x 185 mm | 2834.00 g | 19.42 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4050300816852 | 8330241 | 4934227 | 3820102 | 946537130 |
