Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| FC 22 W/3000 K | 2GX13 | 22 W | 75 V | 12000 h | 1800 lm | Yes |
| FC 22 W/6500 K | 2GX13 | 22 W | 75 V | 12000 h | 1700 lm | Yes |
| FC 40 W/3000 K | 2GX13 | 40 W | 126 V | 12000 h | 3300 lm | Yes |
| FC 40 W/4000 K | 2GX13 | 40 W | 126 V | 12000 h | 3300 lm | Yes |
| FC 40 W/6500 K | 2GX13 | 40 W | 126 V | 12000 h | 3200 lm | Yes |
| FC 55 W/6500 K | 2GX13 | 55 W | 101 V | 12000 h | 3900 lm | Yes |
| Nominal wattage | 22 W |
| Construction wattage | 23.80 W |
| Nominal voltage | 75 V |
| Nominal current | 0.3 A |
| Luminous flux | 1800 lm |
| Luminous efficacy | 76 lm/W |
| Light color (designation) | LUMILUX Warm White |
| Color temperature | 3000 K |
| Color rendering index Ra | ≥80 |
| Light color | 830 |
| Rated LLMF at 2,000 h | 0.85 |
| Rated LLMF at 4,000 h | 0.83 |
| Rated LLMF at 6,000 h | 0.80 |
| Rated LLMF at 8,000 h | 0.80 |
| Rated LLMF at 12,000 h | 0.75 |
| Overall length | 240.00 mm |
| Diameter | 16,0 mm |
| Tube diameter | 16 mm |
| Product weight | 81.00 g |
| Service life | 8000 h 1) |
| Rated lamp survival factor at 2,000 h | 0.99 |
| Rated lamp survival factor at 4,000 h | 0.99 |
| Rated lamp survival factor at 6,000 h | 0.98 |
| Rated lamp survival factor at 8,000 h | 0.92 |
| Rated lamp survival factor at 12,000 h | 0.50 |
| Lifespan B50 | 12000 h |
1) With preheat ECG
| Base (standard designation) | 2GX13 |
| Mercury content | 3.0 mg |
| Product remark | Suitable for ECG operation only |
| Dimmable | Yes |
| Energy efficiency class | G |
| Energy consumption | 24.00 kWh/1000h |
| ILCOS | FSCH-22/830-L/P-2Gx13-16/225 |
| Order reference | FC 22W/830 |
| Lighting technology used | OTHER_FL |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | 2GX13 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 240.00 mm |
| Height | 16,0 mm |
| Width | 16,0 mm |
| Chromaticity coordinate x | 0,440 |
| Chromaticity coordinate y | 0,403 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546400 |
| Model number | AC34175 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300528489 | Folding box 1 |
231 mm x 228 mm x 23 mm | 128.50 g | 1.21 dm³ |
| 4050300528496 | Shipping box 12 |
300 mm x 243 mm x 249 mm | 1865.00 g | 18.15 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4050300528489 | 8330902 | 4931683 | 3835124 | 946203110 |
