Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable | |
|---|---|---|---|---|---|---|---|
| HALOLINE SST 48 W 230 V R7S | R7s | 48 W | 230 V | 2000 h | 700 lm | 60 W | Yes |
| HALOLINE SST 80 W 230 V R7S | R7s | 80 W | 230 V | 2000 h | 1385 lm | Yes | |
| HALOLINE SST 120 W 230 V R7S | R7s | 120 W | 230 V | 2000 h | 2245 lm | Yes | |
| HALOLINE SST 120 W 240 V R7S | R7s | 120 W | 240 V | 2000 h | 2245 lm | Yes | |
| HALOLINE SST 160 W 230 V R7S | R7s | 160 W | 230 V | 2000 h | 3100 lm | 200 W | Yes |
| HALOLINE SST 230 W 230 V R7S | R7s | 230 W | 230 V | 2000 h | 5000 lm | 300 W | Yes |
| HALOLINE SST 400 W 230 V R7S | R7s | 400 W | 230 V | 2000 h | 8750 lm | 500 W | Yes |
| HALOLINE SST 400 W 240 V R7S | R7s | 400 W | 240 V | 2000 h | 8750 lm | 500 W | Yes |
| Nominal wattage | 120 W |
| Construction wattage | 120.00 W |
| Nominal voltage | 230 V |
| Nominal current | 0.52 A |
| Luminous flux | 2245 lm |
| Luminous efficacy | 18 lm/W |
| Light color (designation) | Warm White |
| Color temperature | 2900 K |
| Color rendering index Ra | 100 |
| Light color | 1029 |
| UV protection | No |
| Starting time | 0 s |
| Overall length | 78.00 mm |
| Diameter | 12.00 mm |
| Product weight | 5.6 g |
| Lifespan L70/B50 at 25 °C | 2000 h |
| Base (standard designation) | R7s |
| Mercury-free | Yes |
| Design / version | Tube |
| Product remark | Fuse protection with indicated values recommended acc. to IEC60357, EN60357, For outdoor applications and operation in damp locations special approved fixtures are required |
| Dimmable | Yes |
| Burning position | Any |
| Energy efficiency class | G |
| Energy consumption | 120.00 kWh/1000h |
| ILCOS | HDG-120-230-R7s-74,9 |
| Order reference | 64695 ECO SST |
| Lighting technology used | OTHER |
| Non-directional or directional | NDLS |
| Mains or non-mains | MLS |
| Light source cap-type (or other electric interface) | R7s |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Standby power | 0 W |
| Networked standby power for CLS | not applicable |
| Claim of equivalent power | No |
| Length | 78.00 mm |
| Height | 12.00 mm |
| Width | 12.00 mm |
| Chromaticity coordinate x | 0.444 |
| Chromaticity coordinate y | 0.406 |
| Beam angle correspondence | SPHERE_360 |
| Displacement factor | 1 |
| EPREL ID | 777539,1553999 |
| Model number | AC35330,AC51814 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4008321928931 | Blister 1 |
14 mm x 140 mm x 120 mm | 15.00 g | 0.24 dm³ |
| 4008321327215 | Shipping box 10 |
147 mm x 146 mm x 130 mm | 220.00 g | 2.79 dm³ |
