Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| HQI-T 70 W/WDL | G12 | 70 W | 101 V | 9000 h | 5400 lm | No |
| HQI-T 70 W/NDL UVS | G12 | 70 W | 99 V | 9000 h | 5400 lm | No |
| HQI-T 150 W/WDL UVS | G12 | 150 W | 103 V | 9000 h | 13000 lm | No |
| HQI-T 150 W/NDL UVS | G12 | 150 W | 105 V | 9000 h | 13000 lm | No |
| Nominal wattage | 70 W |
| Construction wattage | 75.00 W |
| Nominal voltage | 101 V |
| Ignition voltage | 3.6/5.0 kVp 1) |
| Operating mode | Conventional control gear (CCG) and ignitor, Electronic control gear (ECG) |
| Nominal current | 0.95 A |
| PFC capacitor at 50 Hz | 12 µF |
1) Minimum / Maximum
| Luminous flux | 5400 lm |
| Luminous efficacy | 72 lm/W |
| Color temperature | 3075 K |
| Color rendering index Ra | 73 |
| Light color | 730 |
| Rated LLMF at 2,000 h | 0.85 |
| Rated LLMF at 4,000 h | 0.80 |
| Rated LLMF at 6,000 h | 0.75 |
| Rated LLMF at 8,000 h | 0.70 |
| UV protection | Yes |
| Overall length | 84.00 mm |
| Light center length (LCL) | 56,0 mm |
| Diameter | 25,0 mm |
| Product weight | 30.00 g |
| Maximum permitted pinch temperature | 280 °C |
| Rated lamp survival factor at 2,000 h | 0.87 |
| Rated lamp survival factor at 4,000 h | 0.85 |
| Rated lamp survival factor at 6,000 h | 0.75 |
| Rated lamp survival factor at 8,000 h | 0.60 |
| Lifespan B50 | 9000 h |
| Base (standard designation) | G12 |
| Mercury content | 13.0 mg |
| Design / version | Clear |
| Dimmable | No |
| Burning position | Any |
| Enclosed luminaire required | Yes |
| Hot restart | No |
| Energy efficiency class | G |
| Energy consumption | 76.00 kWh/1000h |
| ILCOS | MT/UB-70/730-H/E/SL-G12-25/84 |
| Order reference | HQI-T 70W/WDL U |
| Lighting technology used | MH |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | G12 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | SECOND |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 84.00 mm |
| Height | 25,0 mm |
| Width | 25,0 mm |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 666225 |
| Model number | AM42352 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4008321974341 | Folding box 1 |
42 mm x 42 mm x 111 mm | 40.00 g | 0.20 dm³ |
| 4008321974358 | Shipping box 12 |
180 mm x 140 mm x 127 mm | 567.00 g | 3.20 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4008321974341 | 8333056 | 4834671 | 3861016 | 948816470 |
