Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| HQI-E 250 W/D PRO | E40 | 250 W | 105 V | 16000 h | 18000 lm | No |
| HQI-E 400 W/D PRO | E40 | 400 W | 115 V | 16000 h | 34000 lm | No |
| Nominal wattage | 400 W |
| Construction wattage | 430.00 W |
| Nominal voltage | 115 V |
| Ignition voltage | 4.0/5.0 kVp 1) |
| Operating mode | Conventional control gear (CCG) and ignitor |
| Nominal current | 4 A |
| PFC capacitor at 50 Hz | 45 µF |
1) Minimum / Maximum
| Luminous flux | 34000 lm |
| Luminous efficacy | 79 lm/W |
| Color temperature | 5200 K |
| Color rendering index Ra | ≤ 90 |
| Light color | 952 |
| Rated LLMF at 2,000 h | 0.92 |
| Rated LLMF at 4,000 h | 0.90 |
| Rated LLMF at 6,000 h | 0.87 |
| Rated LLMF at 8,000 h | 0.85 |
| Rated LLMF at 12,000 h | 0.81 |
| UV protection | Yes |
| Overall length | 290.00 mm |
| Diameter | 120,0 mm |
| Product weight | 230.00 g |
| Maximum permitted outer bulb temperature | 400 °C |
| Maximum permitted base edge temperature | 250 °C |
| Rated lamp survival factor at 2,000 h | 0.96 |
| Rated lamp survival factor at 4,000 h | 0.94 |
| Rated lamp survival factor at 6,000 h | 0.93 |
| Rated lamp survival factor at 8,000 h | 0.88 |
| Rated lamp survival factor at 12,000 h | 0.81 |
| Lifespan B50 | 16000 h |
| Base (standard designation) | E40 |
| Mercury content | 73.5 mg |
| Design / version | Coated |
| Product remark | With NAV® control gear |
| Dimmable | No |
| Burning position | Any |
| Enclosed luminaire required | Yes |
| Hot restart | No |
| Energy efficiency class | G |
| Energy consumption | 430.00 kWh/1000h |
| ILCOS | ME/UB-250/952-H/E/SL-E40-120/290 |
| Order reference | HQI-E 400W/D PR |
| Lighting technology used | MH |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | E40 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | NON_CLEAR |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 290.00 mm |
| Height | 120,0 mm |
| Width | 120,0 mm |
| Chromaticity coordinate x | 0,340 |
| Chromaticity coordinate y | 0,355 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546559 |
| Model number | AC34333 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4008321677884 | Round wrap 1 |
125 mm x 125 mm x 295 mm | 274.00 g | 4.61 dm³ |
| 4008321677891 | Shipping box 12 |
541 mm x 416 mm x 317 mm | 4239.00 g | 71.34 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4008321677884 | 8333344 | 4834713 | 3860972 | 948801590 |
