Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED PFM CLAS A 9 W/2700 K B22d DIM | B22d | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/2700 K E27 DIM | E27 | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/4000 K B22d DIM | B22d | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| LED PFM CLAS A 9 W/4000 K E27 DIM | E27 | 9 W | 220…240 V | 15000 h | 1055 lm | 75 W | 320 ° | Yes |
| Nominal wattage | 9 W |
| Construction wattage | 9.00 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 75 W |
| Nominal current | 52 mA |
| Type of current | AC |
| Operating frequency | 50…60 Hz |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.50 |
| Luminous flux | 1055 lm |
| Nominal useful luminous flux 90° | 1055 lm |
| Luminous efficacy | 117 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Warm White |
| Color temperature | 2700 K |
| Color rendering index Ra | ≥80 |
| Light color | 827 |
| Beam angle | 320 ° |
| Overall length | 105.00 mm |
| Diameter | 60.00 mm |
| Maximum diameter | 60 mm |
| Product weight | 32.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Base (standard designation) | B22d |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | Yes |
| Type of protection | IP20 |
| Standards | CB, ROHS |
| Photobiological safety group acc. to EN62778 | RG0 |
| Order reference | LPCLADIM 9W/827 |
| Light source cap-type (or other electric interface) | B22d |
| Length | 105.00 mm |
| Height | 60.00 mm |
| Width | 60.00 mm |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075506091 | Folding box 1 |
64 mm x 64 mm x 131 mm | 49.00 g | 0.54 dm³ |
| 4058075506107 | Shipping box 10 |
332 mm x 138 mm x 147 mm | 647.00 g | 6.73 dm³ |
