Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| LED ECO CLA 5 W/3000 K B22d | B22d | 5 W | 220…240 V | 15000 h | 525 lm | No |
| LED ECO CLA 5 W/3000 K E27 | E27 | 5 W | 220…240 V | 15000 h | 525 lm | No |
| LED ECO CLA 5 W/6500 K B22d | B22d | 5 W | 220…240 V | 15000 h | 525 lm | No |
| LED ECO CLA 5 W/6500 K E27 | E27 | 5 W | 220…240 V | 15000 h | 525 lm | No |
| LED ECO CLA 7 W/3000 K B22d | B22d | 7 W | 220…240 V | 15000 h | 735 lm | No |
| LED ECO CLA 7 W/3000 K E27 | E27 | 7 W | 220…240 V | 15000 h | 735 lm | No |
| LED ECO CLA 7 W/6500 K B22d | B22d | 7 W | 220…240 V | 15000 h | 735 lm | No |
| LED ECO CLA 7 W/6500 K E27 | E27 | 7 W | 220…240 V | 15000 h | 735 lm | No |
| LED ECO CLA 9 W/3000 K B22d | B22d | 9 W | 220…240 V | 15000 h | 945 lm | No |
| LED ECO CLA 9 W/3000 K E27 | E27 | 9 W | 220…240 V | 15000 h | 945 lm | No |
| LED ECO CLA 9 W/6500 K B22d | B22d | 9 W | 220…240 V | 15000 h | 945 lm | No |
| LED ECO CLA 9 W/6500 K E27 | E27 | 9 W | 220…240 V | 15000 h | 945 lm | No |
| LED ECO CLA 12 W/3000 K B22d | B22d | 12 W | 220…240 V | 15000 h | 1260 lm | No |
| LED ECO CLA 12 W/3000 K E27 | E27 | 12 W | 220…240 V | 15000 h | 1260 lm | No |
| LED ECO CLA 12 W/6500 K B22d | B22d | 12 W | 220…240 V | 15000 h | 1260 lm | No |
| LED ECO CLA 12 W/6500 K E27 | E27 | 12 W | 220…240 V | 15000 h | 1260 lm | No |
| Nominal wattage | 5 W |
| Construction wattage | 5.00 W |
| Nominal voltage | 220…240 V |
| Nominal current | 33 mA |
| Type of current | AC |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Luminous flux | 525 lm |
| Luminous efficacy | 105 lm/W |
| Light color (designation) | Warm White |
| Color temperature | 3000 K |
| Color rendering index Ra | ≥80 |
| Light color | 830 |
| Standard deviation of color matching | ≤5 sdcm |
| Starting time | ≤ 0.5 s |
| Overall length | 98.00 mm |
| Diameter | 55.00 mm |
| Product weight | 27.00 g |
| Ambient temperature range | -20…+45 °C |
| Base (standard designation) | B22d |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Design / version | Frosted |
| Dimmable | No |
| Type of protection | IP20 |
| Standards | CB, EMC, ROHS |
| Order reference | LECOCLA 5W/830 |
| Light source cap-type (or other electric interface) | B22d |
| Length | 98.00 mm |
| Height | 55.00 mm |
| Width | 55.00 mm |
| Displacement factor | >0.7 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854392436 | Folding box 1 |
56 mm x 56 mm x 105 mm | 41.00 g | 0.33 dm³ |
| 14058075851303 | Bundle 10 |
420 mm x 300 mm | 413.00 g | |
| 4099854392443 | Bundle 10 |
420 mm x 300 mm | 413.00 g | |
| 24058075851317 | Shipping box 100 |
590 mm x 300 mm x 230 mm | 4797.00 g | 40.71 dm³ |
| 4099854392450 | Shipping box 100 |
590 mm x 300 mm x 230 mm | 4797.00 g | 40.71 dm³ |
