Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| PAR 16 100 24 ° 10 W/2700 K GU10 | GU10 | 10 W | 220…240 V | 40000 h | 790 lm | 100 W | 24 ° | Yes |
| PAR 16 100 36 ° 10 W/2700 K GU10 | GU10 | 10 W | 220…240 V | 40000 h | 790 lm | 100 W | 36 ° | Yes |
| PAR 16 100 36 ° 10 W/3000 K GU10 | GU10 | 10 W | 220…240 V | 40000 h | 830 lm | 100 W | 36 ° | Yes |
| PAR 16 100 24 ° 10 W/3000 K GU10 | GU10 | 10 W | 220…240 V | 40000 h | 830 lm | 100 W | 24 ° | Yes |
| PAR 16 100 36 ° 10 W/4000 K GU10 | GU10 | 10 W | 220…240 V | 40000 h | 900 lm | 100 W | 36 ° | Yes |
| PAR 16 100 24 ° 10 W/4000 K GU10 | GU10 | 10 W | 220…240 V | 40000 h | 900 lm | 100 W | 24 ° | Yes |
| Nominal wattage | 10 W |
| Construction wattage | 10.00 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 100 W |
| Nominal current | 48 mA |
| Type of current | AC |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Power factor λ | 0.92 |
| Luminous intensity | 2950 cd |
| Luminous flux | 790 lm |
| Luminous efficacy | 79 lm/W |
| Light color (designation) | Warm White |
| Color temperature | 2700 K |
| Color rendering index Ra | 95 |
| Light color | 927 |
| Standard deviation of color matching | ≤5 sdcm |
| Rated peak intensity | 2950 cd |
| Beam angle | 24 ° |
| Warm-up time (60 %) | ‹ 0.50 s |
| Starting time | < 0.5 s |
| Overall length | 77.30 mm |
| Diameter | 50.00 mm |
| Maximum diameter | 50 mm |
| Product weight | 105.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Base (standard designation) | GU10 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | Yes |
| Energy efficiency class | G 1) |
| Standards | CB, EMC, RoHS |
1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)
| Order reference | LPPAR161102410W |
| Temperature range at storage | -20…+80 °C |
| Light source cap-type (or other electric interface) | GU10 |
| Length | 77.30 mm |
| Height | 50.00 mm |
| Width | 50.00 mm |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075415621 | Folding box 1 |
52 mm x 52 mm x 81 mm | 127.00 g | 0.22 dm³ |
| 4099854262586 | Shipping box 10 |
273 mm x 113 mm x 96 mm | 1378.00 g | 2.96 dm³ |
| 4058075415638 | Shipping box 10 |
273 mm x 113 mm x 96 mm | 1398.00 g | 2.96 dm³ |
| 4099854262593 | Shipping box 60 |
284 mm x 239 mm x 309 mm | 8654.00 g | 20.97 dm³ |
| 4058075415645 | Shipping box 60 |
