Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED VALUE CLAS B 5 W/3000 K E14 GEN2 | E14 | 5 W | 100…240 V | 25000 h | 470 lm | 25 W | 280 ° | No |
| LED VALUE CLAS B 5 W/3000 K E14 GEN2 | E14 | 5 W | 100…240 V | 25000 h | 470 lm | 25 W | 200 ° | No |
| LED VALUE CLAS B 5 W/6500 K E14 GEN2 | E14 | 5 W | 100…240 V | 25000 h | 470 lm | 25 W | 280 ° | No |
| LED VALUE CLAS B 5 W/6500 K E14 GEN2 | E14 | 5 W | 100…240 V | 25000 h | 470 lm | 25 W | 200 ° | No |
| Nominal wattage | 5 W |
| Construction wattage | 5.00 W |
| Nominal voltage | 100…240 V |
| Claimed equiv. conventional lamp power | 25 W |
| Nominal current | 45 mA |
| Type of current | AC |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Power factor λ | > 0.50 |
| Luminous flux | 470 lm |
| Luminous efficacy | 94 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Warm White |
| Color temperature | 3000 K |
| Color rendering index Ra | ≥80 |
| Light color | 830 |
| Standard deviation of color matching | ≤6 sdcm |
| Beam angle | 280 ° |
| Starting time | < 0.5 s |
| Overall length | 100.00 mm |
| Diameter | 37.00 mm |
| Maximum diameter | 37 mm |
| Product weight | 28.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Base (standard designation) | E14 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Dimmable | No |
| Type of protection | IP20 |
| Order reference | LV CLB 5W/830 1 |
| Temperature range at storage | -20…+80 °C |
| Light source cap-type (or other electric interface) | E14 |
| Length | 100.00 mm |
| Height | 37.00 mm |
| Width | 37.00 mm |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075656253 | Folding box 1 |
38 mm x 38 mm x 105 mm | 37.00 g | 0.15 dm³ |
| 4058075656260 | Shipping box 10 |
200 mm x 86 mm x 119 mm | 433.00 g | 2.05 dm³ |
