Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
---|---|---|---|---|---|---|---|---|
P PAR 20 50 36 ° 5 W/2700 K E27 | E27 | 5 W | 220…240 V | 25000 h | 400 lm | 50 W | 36 ° | Yes |
Nominal wattage | 5 W |
Construction wattage | 5.00 W |
Nominal voltage | 220…240 V |
Claimed equiv. conventional lamp power | 50 W |
Nominal current | 23 mA |
Operating frequency | 50…60 Hz |
Mains frequency | 50…60 Hz |
Power factor λ | ≥ 0.70 |
Luminous intensity | 700 cd |
Luminous flux | 400 lm |
Nominal useful luminous flux 90° | 345 lm |
Luminous efficacy | 80 lm/W |
Lumen main.fact.at end of nom.life time | 0.70 |
Light color (designation) | Warm White |
Color temperature | 2700 K |
Color rendering index Ra | ≥80 |
Light color | 827 |
Standard deviation of color matching | ≤6 sdcm |
Rated peak intensity | 700 cd |
Rated LLMF at 6,000 h | 0.80 |
Beam angle | 36 ° |
Warm-up time (60 %) | ‹ 0.50 s |
Starting time | < 0.5 s |
Overall length | 88.00 mm |
Diameter | 64.00 mm |
Maximum diameter | 64 mm |
Product weight | 110.00 g |
Ambient temperature range | -20…+40 °C |
Number of switching cycles | 100000 |
Lumen maintenance at end of service lifetime | 0.70 |
Rated lamp survival factor at 6,000 h | ≥ 0.90 |
Base (standard designation) | E27 |
Mercury content | 0.0 mg |
Mercury-free | Yes |
Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
Dimmable | Yes |
Energy efficiency class | A+ 1) |
Energy consumption | 5.00 kWh/1000h |
Photobiological safety group acc. to EN62778 | RG1 |
1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)
Order reference | LPPAR20D5036 5W |
Light source cap-type (or other electric interface) | E27 |
Length | 88.00 mm |
Height | 64.00 mm |
Width | 64.00 mm |
Minimum rate of recycled material in packaging | 80 % 1) |
Minimum percentage of recycled content in the product | 0 % 1) |
Product recyclability | Mostly recyclable product 1) |
Packaging recyclability | Mostly recyclable packaging 1) |
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4058075184497 | Folding box 1 |
70 mm x 70 mm x 96 mm | 129.00 g | 0.47 dm³ |
4058075184503 | Shipping box 6 |
228 mm x 157 mm x 125 mm | 839.00 g | 4.47 dm³ |
EAN | AU model number |
---|---|
4058075184497 | OSRLEDPAR205W827E27D |
