Professional
PARATHOM® DIM PAR38

PARATHOM DIM PAR38

Choose your product version

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Claimed equiv. conventional lamp power Beam angle Dimmable
P PAR 38 120 30 ° 14.5 W/2700 K E27 E27 14.5 W 220…240 V 25000 h 1200 lm 120 W 30 ° Yes


P PAR 38 120 30 ° 14.5 W/2700 K E27

Product benefits
  • Quick, simple and safe replacement without rewiring
  • Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
  • Low maintenance costs thanks to long lifetime
  • No UV and near-IR radiation in the light beam
  • Stepless dimming
  • Very high dimmer compatibility, see also www.ledvance.com/dim
  • Instant 100 % light, no warm-up time
  • Lower energy consumption than incandescent or halogen lamps

PRODUCT DETAILS

Electrical data

Nominal wattage 14.5 W
Construction wattage 14.50 W
Nominal voltage 220…240 V
Claimed equiv. conventional lamp power 120 W
Nominal current 66 mA
Operating frequency 50…60 Hz
Mains frequency 50…60 Hz
Power factor λ ≥ 0.70

Photometrical data

Luminous intensity 2500 cd
Luminous flux 1200 lm
Nominal useful luminous flux 90° 1035 lm
Luminous efficacy 82 lm/W
Lumen main.fact.at end of nom.life time 0.70
Light color (designation) Warm White
Color temperature 2700 K
Color rendering index Ra ≥80
Light color 827
Standard deviation of color matching ≤6 sdcm
Rated peak intensity 2500 cd
Rated LLMF at 6,000 h 0.80

Light technical data

Beam angle 30 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s

Dimensions & Weight

Overall length 134.00 mm
Diameter 122.00 mm
Maximum diameter 122 mm
Product weight 350.00 g

Temperatures & operating conditions

Ambient temperature range -20…+40 °C

Lifespan

Number of switching cycles 100000
Lumen maintenance at end of service lifetime 0.70
Rated lamp survival factor at 6,000 h ≥ 0.90

Additional product data

Base (standard designation) E27
Mercury content 0.0 mg
Mercury-free Yes
Product remark All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Capabilities

Dimmable Yes

Certificates & Standards

Energy efficiency class A 1)
Energy consumption 15.00 kWh/1000h
Photobiological safety group acc. to EN62778 RG1

1) Energy efficiency class (EEC) on a scale of A++ (highest efficiency) to E (lowest efficiency)

Country-specific categorizations

Order reference LPPR38D12030 14

Energy labelling regulation data acc EU 2019/2015

Light source cap-type (or other electric interface) E27
Length 134.00 mm
Height 122.00 mm
Width 122.00 mm

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Quick, simple and safe replacement without rewiring
  • Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
  • Low maintenance costs thanks to long lifetime
  • No UV and near-IR radiation in the light beam
  • Stepless dimming
  • Very high dimmer compatibility, see also www.ledvance.com/dim
  • Instant 100 % light, no warm-up time
  • Lower energy consumption than incandescent or halogen lamps
Areas of application
  • Shops and exhibition rooms
  • Domestic applications
  • Commercial applications
  • Accent lighting
  • Outdoor use in suitable outdoor luminaires only
Product features
  • LED alternative to high voltage halogen lamps
  • High color consistency: ≤ 6 SDCM
  • Dimmable
  • Base: E27
  • Lamp made of glass
  • Good quality of light; color rendering index Ra: ≥ 80
  • Lifetime: up to 25,000 h
References / Links
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075184558 Folding box
1
127 mm x 129 mm x 170 mm 450.00 g 2.79 dm³
4058075184565 Shipping box
6
402 mm x 278 mm x 196 mm 3069.00 g 21.90 dm³
