Product description	Base (standard designation)	Nominal wattage	Nominal voltage	Nominal lamp life time	Nominal luminous flux	Claimed equiv. conventional lamp power	Beam angle	Dimmable
HQL LED 5400 lm 37 W/2700 K E27	E27	37 W	100…240 V	50000 h	5400 lm	125 W	280 °	No
HQL LED 5400 lm 37 W/2700 K E40	E40	37 W	100…240 V	50000 h	5400 lm	125 W	280 °	No
HQL LED 6000 lm 37 W/4000 K E27	E27	37 W	100…240 V	50000 h	6000 lm	125 W	280 °	No
HQL LED 6000 lm 37 W/4000 K E40	E40	37 W	100…240 V	50000 h	6000 lm	125 W	280 °	No
HQL LED 12000 lm 70 W/4000 K E40	E40	70 W	100…240 V	50000 h	12000 lm	250 W	280 °	No

HQL LED 5400 lm 37 W/2700 K E27

Nominal wattage	37 W
Construction wattage	37.00 W
Nominal voltage	100…240 V
Operating mode	AC Mains, Conventional control gear (CCG)
Claimed equiv. conventional lamp power	125 W
Nominal current	400 mA
Type of current	AC
Operating frequency	50/60 Hz
Mains frequency	50/60 Hz
Total harmonic distortion	< 20 %
Power factor λ	0.90

Luminous flux	5400 lm
Nominal useful luminous flux 90°	5400 lm
Luminous efficacy	145 lm/W
Light color (designation)	Warm White
Color temperature	2700 K
Color rendering index Ra	≥80
Light color	827

Ambient temperature range

-20…+50 °C

Number of switching cycles

100000

Base (standard designation)	E27
Mercury content	0.0 mg

Dimmable

Type of protection	IP65
Standards	CB
Photobiological safety group acc. to EN62778	RG1

Order reference

HQLLED 37W/827

Light source cap-type (or other electric interface)	E27
Length	195.00 mm
Height	80.00 mm
Width	80.00 mm

Product benefits

Areas of application

Product features

Replacement for HQL: Suitable for operation with conventional control gear (CCG) for HQL or 100-240V mains
Replacement for other HID: Suitable for operation with line voltage without control gear
Power factor: 0.9
Type of protection: IP65
High surge protection: up to 4 kV (L-N)

Safety advice

The bulb may be larger and heavier than the replaced bulb. Before installation it must be checked, if the luminaire and especially the holder is capable of carrying the weight of the lamp. If possible, please install the safety rope included in the package containing the lamp for the types 37W E40 and 70W E40.
Not suitable for operation with ignitors
Operation on the capacitor can lead to a reduction of the power factor of the system.
When installed horizontally, the t_c point of the lamp is located on the top side of the lamp.
Use in tight luminaires and luminaires with tight reflectors not recommended.
