Professional

LED ECO LITE DAMPPROOF HOUSING G2

Choose your product version

NEW


LED ECO LITE DAMP PROOF HOUSING SE G2 1200

Product benefits
  • UV stabilized, impact resistant polycarbonate diffuser and body
  • VDE certified components ensure product reliability

PRODUCT DETAILS

Electrical data

Nominal voltage 100…277 V
Mains frequency 50…60 Hz
Protection class I

Dimensions & Weight

Length 1277.00 mm
Height 67.00 mm
Width 109.00 mm
Product weight 1287.00 g

Materials & Colors

Product color Gray
Housing color Gray
Body material Polycarbonate (PC)

Application & Mounting

Ambient temperature range -20…+45 °C
Type of protection IP65
Dimmable No
Mounting type Surface/Suspended
Application environment Indoor

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • UV stabilized, impact resistant polycarbonate diffuser and body
  • VDE certified components ensure product reliability
Areas of application
  • Industrial and storage facilities
  • Car parks
  • Garages
  • Workshops, assembly lines
Product features
  • Lifetime up to 25,000 h
  • Protection class: I
  • Protection rating: IP65
  • Classic design with PC body and PC diffuser
  • Back-plate to cover wires
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4099854514111 Folding box
1
112 mm x 69 mm x 1,279 mm 1355.00 g 9.88 dm³
4099854514128 Shipping box
8
1,300 mm x 240 mm x 305 mm 11918.00 g 95.16 dm³
