Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| DL SLIM SQ 105 6 W 3000 K WT | 6.00 W | 50000 | 120 ° | 420 lm | No |
| DL SLIM SQ 105 6 W 4000 K WT | 6.00 W | 50000 | 120 ° | 430 lm | No |
| DL SLIM SQ 105 6 W 6500 K WT | 6.00 W | 50000 | 120 ° | 430 lm | No |
| DL SLIM SQ 155 12 W 3000 K WT | 12.00 W | 50000 | 120 ° | 1020 lm | No |
| DL SLIM SQ 155 12 W 4000 K WT | 12.00 W | 50000 | 120 ° | 1020 lm | No |
| DL SLIM SQ 155 12 W 6500 K WT | 12.00 W | 50000 | 120 ° | 1020 lm | No |
| DL SLIM SQ 210 18 W 3000 K WT | 18.00 W | 50000 | 120 ° | 1530 lm | No |
| DL SLIM SQ 210 18 W 4000 K WT | 18.00 W | 50000 | 120 ° | 1530 lm | No |
| DL SLIM SQ 210 18 W 6500 K WT | 18.00 W | 50000 | 120 ° | 1530 lm | No |
| Nominal wattage | 18.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 108 mA |
| Inrush current | 17 A |
| Inrush current time Th50 | 56 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 44 |
| Max. number of luminaires per miniature circuit breaker C10 | 35 |
| Max. number of luminaires per miniature circuit breaker C16 | 56 |
| Power factor λ | 0.50 |
| Total harmonic distortion | < 20 % |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 1530 lm |
| Luminous efficacy | 85 lm/W |
| Color temperature | 6500 K |
| Light color (designation) | Cool Daylight |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 6 sdcm |
| Luminous intensity | - |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 120 ° |
| Length | 225.00 mm |
| Height | 30.00 mm |
| Width | 225.00 mm |
| Product weight | 527.00 g |
| Product color | White |
| Housing color | White |
| Body material | Polycarbonate (PC) |
| Cover material | Polycarbonate (PC) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+50 °C |
| Temperature range at storage | -30…+70 °C |
| Type of connection | Screwless terminal, 2-Pole |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Recessed |
| Mounting location | Ceiling, Wall |
| Application environment | Indoor |
| Mounting length | 210,0 mm |
| Mounting width | 210,0 mm |
| Mounting depth | 50,0 mm |
| LED module replaceable | Not replaceable |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Lifespan L80/B10 at 25 °C | 20000 h 1) |
| Lifespan L90/B10 at 25 °C | 12000 h |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 295 mA |
| ECG - Output ripple current | < 6.5 % |
| Standards | CE, CB, EAC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Number of illuminants | Not relevant |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075079373 | Folding box 1 |
45 mm x 250 mm x 230 mm | 610.00 g | 2.59 dm³ |
| 4058075079380 | Shipping box 6 |
290 mm x 260 mm x 250 mm | 3991.00 g | 18.85 dm³ |
| Product image | Product name | EAN |
|---|---|---|
|
DL SLIM FRAME SQ 210 WT | 4058075079434 |
| EAN | STK number | ELDAS number |
|---|---|---|
| 4058075079373 | 4295648 | 941400290 |
