Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| FL FLEX P 40W ML 830 A45X140 WAL | 40 W / 34 W / 28 W / 22 W | 100000 | 45 ° x 140 ° | 5800 lm / 4900 lm / 4100 lm / 3300 lm | No |
| FL FLEX P 40W ML 840 A45X140 WAL | 40 W / 34 W / 28 W / 22 W | 100000 | 45 ° x 140 ° | 6100 lm / 5200 lm / 4300 lm / 3500 lm | No |
| FL FLEX P 80W ML 822 A45X140 WAL | 80 W / 68 W / 56 W / 44 W | 100000 | 45 ° x 140 ° | 8300 lm / 7100 lm / 5900 lm / 4700 lm | No |
| FL FLEX P 80W ML 830 A45X140 WAL | 80 W / 68 W / 56 W / 44 W | 100000 | 45 ° x 140 ° | 11400 lm / 9700 lm / 8100 lm / 6500 lm | No |
| FL FLEX P 80W ML 840 A45X140 WAL | 80 W / 68 W / 56 W / 44 W | 100000 | 45 ° x 140 ° | 12000 lm / 10200 lm / 8500 lm / 6800 lm | No |
| FL FLEX P 130W ML 830 A45X140 WAL | 130 W / 110.5 W / 91.0 W / 71.5 W | 100000 | 45 ° x 140 ° | 19000 lm / 16200 lm / 13500 lm / 10800 lm | No |
| FL FLEX P 130W ML 840 A45X140 WAL | 130 W / 110.5 W / 91.0 W / 71.5 W | 100000 | 45 ° x 140 ° | 19800 lm / 16800 lm / 14100 lm / 11300 lm | No |
| FL FLEX P 180W ML 830 A45X140 WAL | 180 W / 153 W / 126 W / 99 W | 100000 | 45 ° x 140 ° | 25500 lm / 21700 lm / 18100 lm / 14500 lm | No |
| FL FLEX P 180W ML 840 A45X140 WAL | 180 W / 153 W / 126 W / 99 W | 100000 | 45 ° x 140 ° | 27500 lm / 23400 lm / 19500 lm / 15700 lm | No |
| FL FLEX P 250W ML 830 A45X140 WAL | 250 W / 212.5 W / 175 W / 137.5 W | 100000 | 45 ° x 140 ° | 37000 lm / 31500 lm / 26300 lm / 21100 lm | No |
| FL FLEX P 250W ML 840 A45X140 WAL | 250 W / 212.5 W / 175 W / 137.5 W | 100000 | 45 ° x 140 ° | 39000 lm / 33200 lm / 27700 lm / 22200 lm | No |
| FL FLEX P 360W ML 830 A45X140 WAL | 360 W / 306 W / 252 W / 198 W | 100000 | 45 ° x 140 ° | 52000 lm / 44200 lm / 36900 lm / 29600 lm | No |
| FL FLEX P 360W ML 840 A45X140 WAL | 360 W / 306 W / 252 W / 198 W | 100000 | 45 ° x 140 ° | 56000 lm / 47600 lm / 39800 lm / 31900 lm | No |
| FL FLEX P 450W ML 830 A45X140 WAL | 450 W / 382.5 W / 315 W / 247.5 W | 100000 | 45 ° x 140 ° | 60000 lm / 55300 lm / 46200 lm / 37100 lm | No |
| FL FLEX P 450W ML 840 A45X140 WAL | 450 W / 382.5 W / 315 W / 247.5 W | 100000 | 45 ° x 140 ° | 70000 lm / 59500 lm / 49700 lm / 39900 lm | No |
| Nominal wattage | 40 W / 34 W / 28 W / 22 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 184.000 mA |
| Inrush current | 66.4 A |
| Inrush current time Th50 | 166 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 12 |
| Max. number of luminaires per miniature circuit breaker C10 | 12 |
| Max. number of luminaires per miniature circuit breaker C16 | 20 |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 20 % |
| Protection class | I |
| Surge capability (L-N) | 6 kV |
| Surge capability (L/N-Ground) | 10 kV |
| Operating mode | Integrated LED driver |
| Luminous flux | 5800 lm / 4900 lm / 4100 lm / 3300 lm |
| Luminous efficacy | 145 lm/W / 144 lm/W / 146 lm/W / 150 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | 5 sdcm |
| Luminous intensity | 3626 cd |
| Low flicker | Yes |
| Flickering metric (Pst LM) | <1 |
| Stroboscope effect metric (SVM) | <0.4 |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 45 ° x 140 ° |
| Length | 406.00 mm |
| Height | 67.00 mm |
| Width | 277.00 mm |
| Product weight | 3600.00 g |
| Product color | White aluminum |
| Housing color | White aluminum |
| Body material | Aluminum |
| Cover material | Glass |
| Light emitting surface material | Glass |
| Glow Wire Test according to IEC 60695-2-12 | 850 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -30…+50 °C |
| Temperature range at storage | -30…+80 °C |
| Type of connection | Screwless terminal |
| Type of protection | IP66 |
| Protection class IK (shock resistance) | IK08 |
| Corrosion resistance class acc. to EN 12944 | C5 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall, Pole, Floor, Ceiling |
| Application environment | Outdoor |
| Adjustable | Yes |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 120000 h 1) |
| Lifespan L80/B10 at 25 °C | 100000 h 1) |
| Lifespan L90/B10 at 25 °C | 50000 h |
| Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 1300 mA |
| ECG - Output ripple current | < 10 % |
| Standards | CE, CB, ENEC, UKCA |
| Luminaire with limited surface temperature, "D sign" | Yes |
| Replaceable light source (EPREL) | Not replaceable |
| Product remark | Available from December 2024 |
| Added function | MULTI SELECT |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1), Alkanes / Chloroalkanes C10-13 (85535-84-8) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854373152 | Shipping box 1 |
482 mm x 322 mm x 114 mm | 4605.00 g | 17.69 dm³ |
| EAN | SEG number | STK number | EFO number |
|---|---|---|---|
| 4099854373152 | 7770383 | 4532007 | 3228589 |
