Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED VALUE FLOODLIGHT 300W 4000K 120X90DEG IP66 | 300.00 W | 30000 | 120 ° x 90 ° | 42000 lm | No |
| LED VALUE FLOODLIGHT 300W 4000K 30DEG IP66 | 300.00 W | 30000 | 30 ° | 42000 lm | No |
| LED VALUE FLOODLIGHT 300W 4000K 60DEG IP66 | 300.00 W | 30000 | 60 ° | 42000 lm | No |
| LED VALUE FLOODLIGHT 300W 6500K 30DEG IP66 | 300.00 W | 30000 | 30 ° | 42000 lm | No |
| LED VALUE FLOODLIGHT 300W 6500K 120X90DEG IP66 | 300.00 W | 30000 | 120 ° x 90 ° | 42000 lm | No |
| LED VALUE FLOODLIGHT 300W 6500K 60DEG IP66 | 300.00 W | 30000 | 60 ° | 42000 lm | No |
| LED VALUE FLOODLIGHT 500W 4000K 60DEG IP66 | 500.00 W | 30000 | 60 ° | 72000 lm | No |
| LED VALUE FLOODLIGHT 500W 4000K 120X90DEG IP66 | 500.00 W | 30000 | 120 ° x 90 ° | 72000 lm | No |
| LED VALUE FLOODLIGHT 500W 4000K 30DEG IP66 | 500.00 W | 30000 | 30 ° | 72000 lm | No |
| LED VALUE FLOODLIGHT 500W 6500K 60DEG IP66 | 500.00 W | 30000 | 60 ° | 72000 lm | No |
| LED VALUE FLOODLIGHT 500W 6500K 120X90DEG IP66 | 500.00 W | 30000 | 120 ° x 90 ° | 72000 lm | No |
| LED VALUE FLOODLIGHT 500W 6500K 30DEG IP66 | 500.00 W | 30000 | 30 ° | 72000 lm | No |
| Nominal wattage | 300.00 W |
| Nominal voltage | 100…277 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 1.96…5 A |
| Inrush current time Th50 | 1800 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 3 |
| Max. number of luminaires per miniature circuit breaker C16 | 6 |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 20 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 42000 lm |
| Luminous efficacy | 140 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | < 5 sdcm |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 120 ° x 90 ° |
| Length | 432.00 mm |
| Height | 105.00 mm |
| Width | 445.00 mm |
| Product weight | 6600.00 g |
| Cable length | 500 mm |
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 750 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -30…+50 °C |
| Type of connection | Cable, 3-pole |
| Type of protection | IP66 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall, Pole |
| Mounting width | 300 mm |
| Adjustable | Yes |
| Replaceable light source (EPREL) | Not replaceable |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Number of switching cycles | 30000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CB, EMC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854148279 | Shipping box 1 |
582 mm x 457 mm x 192 mm | 8228.00 g | 51.07 dm³ |
| EAN | AU model number |
|---|---|
| 4099854148279 | LDVFL300WASY840 |
