Professional

LED PERFORMANCE HIGHPOWER FLOODLIGHT

Choose your product version

400W 840 40X85D

400W 840 30D

400W 840 55D

400W 840 90D

LDPFM FL HP 400

LDPFM FL HP400W

LDPFM FL HP 400

LDPFM FL HP 400

400W 865 30D

400W 865 55D

400W 865 90D

400W 865 40X85D

LDPFM FL HP400W

LDPFM FL HP 400

LDPFM FL HP 400

LDPFM FL HP 400

500W 840 40X85D

500W 840 30D

500W 840 55D

500W 840 90D

500W 865 30D

500W 865 55D

500W 865 90D

500W 865 40X85D

600W 840 40X85D

600W 840 55D

600W 840 90D

600W 840 30D

LDPFM FL HP 600

LDPFM FL HP 600

LDPFM FL HP600W

LDPFM FL HP 600

600W 865 90D

600W 865 40X85D

LDPFM FL HP 600

600W 865 30D

600W 865 55D

LDPFM FL HP 600

LDPFM FL HP 600

LDPFM FL HP600W

800W 840 40X85D

800W 840 30D

800W 840 55D

800W 840 90D

800W 865 30D

800W 865 55D

800W 865 90D

800W 865 40X85D

1KW 840 40X85D

1KW 840 30D

OVERVIEW

Product description Nominal wattage Beam angle Luminous flux Dimmable
LED PERFORMANCE HP FLOOD 400W 840 40X85D 400.00 W 40 ° x 85 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 840 30D 400.00 W 30 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 840 55D 400.00 W 55 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 840 90D 400.00 W 90 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP 400 400.00 W 90 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP400W 400.00 W 40 ° x 85 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP 400 400.00 W 30 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP 400 400.00 W 55 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 865 30D 400.00 W 30 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 865 55D 400.00 W 55 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 865 90D 400.00 W 90 ° 48000 lm No
LED PERFORMANCE HP FLOOD 400W 865 40X85D 400.00 W 40 ° x 85 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP400W 400.00 W 40 ° x 85 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP 400 400.00 W 30 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP 400 400.00 W 55 ° 48000 lm No
FLOODLIGHT LED LDPFM FL HP 400 400.00 W 90 ° 48000 lm No
LED PERFORMANCE HP FLOOD 500W 840 40X85D 500.00 W 40 ° x 85 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 840 30D 500.00 W 30 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 840 55D 500.00 W 55 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 840 90D 500.00 W 90 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 865 30D 500.00 W 30 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 865 55D 500.00 W 55 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 865 90D 500.00 W 90 ° 60000 lm No
LED PERFORMANCE HP FLOOD 500W 865 40X85D 500.00 W 40 ° x 85 ° 60000 lm No
LED PERFORMANCE HP FLOOD 600W 840 40X85D 600.00 W 40 ° x 85 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 840 55D 600.00 W 55 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 840 90D 600.00 W 90 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 840 30D 600.00 W 30 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP 600 600.00 W 55 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP 600 600.00 W 90 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP600W 600.00 W 40 ° x 85 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP 600 600.00 W 30 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 865 90D 600.00 W 90 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 865 40X85D 600.00 W 40 ° x 85 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP 600 600.00 W 30 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 865 30D 600.00 W 30 ° 72000 lm No
LED PERFORMANCE HP FLOOD 600W 865 55D 600.00 W 55 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP 600 600.00 W 90 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP 600 600.00 W 55 ° 72000 lm No
FLOODLIGHT LED LDPFM FL HP600W 600.00 W 40 ° x 85 ° 72000 lm No
LED PERFORMANCE HP FLOOD 800W 840 40X85D 800.00 W 40 ° x 85 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 840 30D 800.00 W 30 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 840 55D 800.00 W 55 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 840 90D 800.00 W 90 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 865 30D 800.00 W 30 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 865 55D 800.00 W 55 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 865 90D 800.00 W 90 ° 96000 lm No
LED PERFORMANCE HP FLOOD 800W 865 40X85D 800.00 W 40 ° x 85 ° 96000 lm No
LED PERFORMANCE HP FLOOD 1KW 840 40X85D 1000.00 W 40 ° x 85 ° 120000 lm No
LED PERFORMANCE HP FLOOD 1KW 840 30D 1000.00 W 30 ° 120000 lm No


LED PERFORMANCE HP FLOOD 400W 840 40X85D

Product benefits
  • Dust and water protection according to IP65
  • Designed for extra performance
  • Low maintenance costs thanks to long lifetime
  • Aesthetic and functional product design
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 400.00 W
Nominal voltage 100…240 V
Mains frequency 50…60 Hz
Power factor λ ≥0.90
Total harmonic distortion < 20 %
Protection class I

Photometrical data

Luminous flux 48000 lm
Luminous efficacy 120 lm/W
Color temperature 4000 K
Light color (designation) Cool White
Color rendering index Ra ≥80
Beam angle 40 ° x 85 °

Dimensions & Weight

Length 522.00 mm
Height 152.00 mm
Width 466.00 mm
Product weight 15000.00 g

Materials & Colors

Product color Black
Housing color Black
Body material Aluminum
Cover material Polycarbonate (PC)
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -30…+50 °C
Type of connection Cable, 3-pole
Type of protection IP65
Protection class IK (shock resistance) IK08
Dimmable No
Mounting type Standing|Surface
Mounting location Ground, Pole

Lifespan

Lifespan L70/B50 at 25 °C 50000 h 1)

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Certificates & Standards

Replaceable light source (EPREL) Not replaceable

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Dust and water protection according to IP65
  • Designed for extra performance
  • Low maintenance costs thanks to long lifetime
  • Aesthetic and functional product design
Areas of application
  • Airports
  • Area lighting
  • Sports facilities
  • Mast or wall mounting
  • Outdoor use (IP65)
Product features
  • Die-cast aluminum housing
  • Luminous efficacy: up to 120 lm/W
  • Available with color temperature: 4,000 K, 6,500 K
  • Lifetime (L70/B50): 50,000 h
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075418615 Shipping box
1		 600 mm x 540 mm x 230 mm 16421.00 g 74.52 dm³
Product image: white background, spacial
LDPFM FL HP 400W MV JPG (2.25 MB)
Product line drawing with numbers
LDPFM FL HP 400W MV SVG (4.51 MB)
IES file (IES)
LDPFM FL HP 400W 840 4 0X85D IES (25.09 KB)
