Professional
LED VALUE CANOPY LIGHT

LED VALUE CANOPY LIGHT

Choose your product version

MSF 60W 840 W

MSF 60W 840 M

MSF 60W 840 ASY

MRE 60W 840 ASY

MRE 60W 840 W

MRE 60W 840 M

MSF 60W 865 M

MRE 60W 865 W

MSF 60W 865 W

MRE 60W 865 M

MRE 60W 865 ASY

MSF 60W 865 ASY

MSF 90W 840 M

MSF 90W 840 ASY

MSF 90W 840 W

MRE 90W 840 ASY

MRE 90W 840 W

MRE 90W 840 M

MRE 90W 865 M

MSF 90W 865 ASY

MSF 90W 865 W

MSF 90W 865 M

MRE 90W 865 ASY

MRE 90W 865 W

MSF 110W 840 W

MSF 110W 840 ASY

MRE 110W 840 ASY

MSF 110W 840 M

MRE 110W 840 M

MRE 110W 840 W

MSF 110W 865 M

MSF 110W 865 W

MRE 110W 865 W

MSF 110W 865 ASY

MRE 110W 865 ASY

MRE 110W 865 M

OVERVIEW

Product description Nominal wattage Beam angle Luminous flux Dimmable
LED VALUE CANOPY MSF 60W 840 W 60.00 W 120 ° 8100 lm No
LED VALUE CANOPY MSF 60W 840 M 60.00 W 90 ° 8100 lm No
LED VALUE CANOPY MSF 60W 840 ASY 60.00 W 120 ° x 60 ° 8100 lm No
LED VALUE CANOPY MRE 60W 840 ASY 60.00 W 120 ° x 60 ° 8100 lm No
LED VALUE CANOPY MRE 60W 840 W 60.00 W 120 ° 8100 lm No
LED VALUE CANOPY MRE 60W 840 M 60.00 W 90 ° 8100 lm No
LED VALUE CANOPY MSF 60W 865 M 60.00 W 90 ° 8100 lm No
LED VALUE CANOPY MRE 60W 865 W 60.00 W 120 ° 8100 lm No
LED VALUE CANOPY MSF 60W 865 W 60.00 W 120 ° 8100 lm No
LED VALUE CANOPY MRE 60W 865 M 60.00 W 90 ° 8100 lm No
LED VALUE CANOPY MRE 60W 865 ASY 60.00 W 120 ° x 60 ° 8100 lm No
LED VALUE CANOPY MSF 60W 865 ASY 60.00 W 120 ° x 60 ° 8100 lm No
LED VALUE CANOPY MSF 90W 840 M 90.00 W 90 ° 12150 lm No
LED VALUE CANOPY MSF 90W 840 ASY 90.00 W 120 ° x 60 ° 12150 lm No
LED VALUE CANOPY MSF 90W 840 W 90.00 W 120 ° 12150 lm No
LED VALUE CANOPY MRE 90W 840 ASY 90.00 W 120 ° x 60 ° 12150 lm No
LED VALUE CANOPY MRE 90W 840 W 90.00 W 120 ° 12150 lm No
LED VALUE CANOPY MRE 90W 840 M 90.00 W 90 ° 12150 lm No
LED VALUE CANOPY MRE 90W 865 M 90.00 W 90 ° 12150 lm No
LED VALUE CANOPY MSF 90W 865 ASY 90.00 W 120 ° x 60 ° 12150 lm No
LED VALUE CANOPY MSF 90W 865 W 90.00 W 120 ° 12150 lm No
LED VALUE CANOPY MSF 90W 865 M 90.00 W 90 ° 12150 lm No
LED VALUE CANOPY MRE 90W 865 ASY 90.00 W 120 ° x 60 ° 12150 lm No
LED VALUE CANOPY MRE 90W 865 W 90.00 W 120 ° 12150 lm No
LED VALUE CANOPY MSF 110W 840 W 110.00 W 120 ° 14850 lm No
LED VALUE CANOPY MSF 110W 840 ASY 110.00 W 120 ° x 60 ° 14850 lm No
LED VALUE CANOPY MRE 110W 840 ASY 110.00 W 120 ° x 60 ° 14850 lm No
LED VALUE CANOPY MSF 110W 840 M 110.00 W 90 ° 14850 lm No
LED VALUE CANOPY MRE 110W 840 M 110.00 W 90 ° 14850 lm No
LED VALUE CANOPY MRE 110W 840 W 110.00 W 120 ° 14850 lm No
LED VALUE CANOPY MSF 110W 865 M 110.00 W 90 ° 14850 lm No
LED VALUE CANOPY MSF 110W 865 W 110.00 W 120 ° 14850 lm No
LED VALUE CANOPY MRE 110W 865 W 110.00 W 120 ° 14850 lm No
LED VALUE CANOPY MSF 110W 865 ASY 110.00 W 120 ° x 60 ° 14850 lm No
LED VALUE CANOPY MRE 110W 865 ASY 110.00 W 120 ° x 60 ° 14850 lm No
LED VALUE CANOPY MRE 110W 865 M 110.00 W 90 ° 14850 lm No


LED VALUE CANOPY MSF 60W 840 W

Product benefits
  • Low maintenance costs thanks to long lifetime
  • Pre-wired with mains cable
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 60.00 W
Nominal voltage 220…240 V
Protection class I

Photometrical data

Luminous flux 8100 lm
Luminous efficacy 135 lm/W
Color temperature 4000 K
Standard deviation of color matching < 5 sdcm
Beam angle 120 °

Dimensions & Weight

Length 302.00 mm
Height 93.00 mm
Width 302.00 mm
Product weight 3900.00 g

Materials & Colors

Body material Aluminum
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -30…+50 °C
Type of protection IP66
Dimmable No
Mounting type Surface
Mounting location Ceiling, Pole
Application environment Outdoor

Certificates & Standards

Standards CB
Replaceable light source (EPREL) Not replaceable

Additional product data

BEG eligible No

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Low maintenance costs thanks to long lifetime
  • Pre-wired with mains cable
Areas of application
  • Petrol station
  • Indoor low-high space ceiling applications
  • Logistics halls
  • Canopy lighting
Product features
  • Available with wattage: 60 W, 90 W and 110 W
  • Available in surface mounting, recessed mounting and pole mounting
  • System efficacy 135 lm/W provides high energy saving compare to conventional HID product
  • Beam angle: symmetric middle (90°), symmetric wide (120°), asymmetric (120° x 60°)
  • Die cast aluminum housing provides good heat dissipation
  • Secondary optics - tempered glass cover, helps to ensure the stability of product performance
  • Type of protection: IP66
  • Impact resistance: IK07
  • Available with color temperature: 4,000 K, 6,500 K
  • Color rendering index Ra: > 80
  • Color consistency: SDCM <5
  • Certificate: CB, EMC, RoHS
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075539310 Shipping box
1		 362 mm x 362 mm x 122 mm 4488.00 g 15.99 dm³
Product Image, Upright, White BG
LDVAL CANOPY MSF JPG (1.91 MB)
Product line drawing with numbers
LDVAL CANOPY MSF 60W SVG (209.39 KB)
