Choose your product version
| Product description | Nominal wattage | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|
| LED PERFORMANCE TRI CCT HIGHBAY 60 W/ 80 W/ 100 W | 100.00 W | 90 ° | 14000 lm | Yes |
| LED PERFORMANCE TRI CCT HIGHBAY 125 W/ 150 W/ 200 W | 200.00 W | 90 ° | 28000 lm | Yes |
| Nominal wattage | 200.00 W |
| Mains frequency | 50…60 Hz |
| Nominal current | 0.8…2.1 A |
| Max. number of luminaires per miniature circuit breaker B16 | 5 |
| Protection class | I |
| Luminous flux | 28000 lm |
| Luminous efficacy | 140 lm/W |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | < 5 sdcm |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 90 ° |
| Diameter | 340.00 mm |
| Height | 146.00 mm |
| Product weight | 3100.00 g |
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Mercury content | 0.0 mg |
| Temperature range at storage | -40…+70 °C |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | Yes |
| Type of dimming | 1-10V |
| LED module replaceable | Not replaceable |
| With light source | Yes |
| Lifespan L80/B10 at 25 °C | 100000 h 1) |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Ball shot safe | No |
| Number of illuminants | 1 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854115639 | Shipping box 1 |
365 mm x 365 mm x 137 mm | 3695.00 g | 18.25 dm³ |
