Professional

LED LOW UGR SPOT LIGHT

Choose your product version

7 W 2700 K 15 ° ADJ

7 W 2700 K 15 °

7 W 2700 K 36 °

7 W 2700 K 24 ° ADJ

7 W 4000 K 36 ° OV

7 W 4000 K 15 ° OV

7 W 4000 K 24 ° OV

7 W 4000 K 36 ° NB

7 W 4000 K 15 ° NB

7 W 4000 K 24 ° NB

7 W 3000 K 15 °

7 W 3000 K 36 °

7 W 3000 K 15 ° ADJ

7 W 3000 K 24 ° ADJ

7 W 3000 K 36 ° ADJ

7 W 3000 K 24 °

7 W 4000 K 15 ° ADJ

7 W 4000 K 24 ° ADJ

7 W 4000 K 36 °

7 W 4000 K 24 °

7 W 4000 K 15 °

7 W 4000 K 36 ° ADJ

9 W 2700 K 15 ° OV

9 W 2700 K 36 ° OV

9 W 2700 K 36 ° NB

9 W 2700 K 24 ° OV

9 W 2700 K 24 ° NB

9 W 2700 K 15 ° NB

9 W 3000 K 24 ° NB

9 W 3000 K 24 ° OV

9 W 3000 K 15 ° NB

9 W 3000 K 36 ° NB

9 W 3000 K 36 ° OV

9 W 3000 K 15 ° OV

9 W 2700 K 15 ° ADJ

9 W 2700 K 36 ° ADJ

9 W 2700 K 24 °

9 W 2700 K 36 °

9 W 2700 K 15 °

9 W 2700 K 24 ° ADJ

9 W 4000 K 36 ° OV

9 W 4000 K 36 ° NB

9 W 4000 K 15 ° NB

9 W 4000 K 24 ° OV

9 W 4000 K 24 ° NB

9 W 4000 K 15 ° OV

9 W 3000 K 15 °

9 W 3000 K 24 °

9 W 3000 K 24 ° ADJ

9 W 3000 K 36 ° ADJ

OVERVIEW

Product description Nominal wattage Number of switching cycles Beam angle Luminous flux Dimmable
LED Performance LUGR Spotlight 7 W 2700 K 15 ° ADJ 7.00 W 30000 15 ° 385 lm No
LED Performance LUGR Spotlight 7 W 2700 K 15 ° 7.00 W 30000 15 ° 385 lm No
LED Performance LUGR Spotlight 7 W 2700 K 36 ° 7.00 W 30000 36 ° 385 lm No
LED Performance LUGR Spotlight 7 W 2700 K 24 ° ADJ 7.00 W 30000 24 ° 385 lm No
LED Performance LUGR Spotlight 7 W 4000 K 36 ° OV 7.00 W 30000 36 ° 385 lm No
LED Performance LUGR Spotlight 7 W 4000 K 15 ° OV 7.00 W 30000 15 ° 385 lm No
LED Performance LUGR Spotlight 7 W 4000 K 24 ° OV 7.00 W 30000 24 ° 385 lm No
LED Performance LUGR Spotlight 7 W 4000 K 36 ° NB 7.00 W 30000 36 ° 385 lm No
LED Performance LUGR Spotlight 7 W 4000 K 15 ° NB 7.00 W 30000 15 ° 385 lm No
LED Performance LUGR Spotlight 7 W 4000 K 24 ° NB 7.00 W 30000 24 ° 385 lm No
LED Performance LUGR Spotlight 7 W 3000 K 15 ° 7.00 W 30000 15 ° 400 lm No
LED Performance LUGR Spotlight 7 W 3000 K 36 ° 7.00 W 30000 36 ° 400 lm No
LED Performance LUGR Spotlight 7 W 3000 K 15 ° ADJ 7.00 W 30000 15 ° 400 lm No
LED Performance LUGR Spotlight 7 W 3000 K 24 ° ADJ 7.00 W 30000 24 ° 400 lm No
LED Performance LUGR Spotlight 7 W 3000 K 36 ° ADJ 7.00 W 30000 36 ° 400 lm No
LED Performance LUGR Spotlight 7 W 3000 K 24 ° 7.00 W 30000 24 ° 400 lm No
LED Performance LUGR Spotlight 7 W 4000 K 15 ° ADJ 7.00 W 30000 15 ° 415 lm No
LED Performance LUGR Spotlight 7 W 4000 K 24 ° ADJ 7.00 W 30000 24 ° 415 lm No
LED Performance LUGR Spotlight 7 W 4000 K 36 ° 7.00 W 30000 36 ° 415 lm No
LED Performance LUGR Spotlight 7 W 4000 K 24 ° 7.00 W 30000 24 ° 415 lm No
LED Performance LUGR Spotlight 7 W 4000 K 15 ° 7.00 W 30000 15 ° 415 lm No
LED Performance LUGR Spotlight 7 W 4000 K 36 ° ADJ 7.00 W 30000 36 ° 415 lm No
LED Performance LUGR Spotlight 9 W 2700 K 15 ° OV 9.00 W 30000 15 ° 450 lm No
LED Performance LUGR Spotlight 9 W 2700 K 36 ° OV 9.00 W 30000 36 ° 450 lm No
LED Performance LUGR Spotlight 9 W 2700 K 36 ° NB 9.00 W 30000 36 ° 450 lm No
LED Performance LUGR Spotlight 9 W 2700 K 24 ° OV 9.00 W 30000 24 ° 450 lm No
LED Performance LUGR Spotlight 9 W 2700 K 24 ° NB 9.00 W 30000 24 ° 450 lm No
LED Performance LUGR Spotlight 9 W 2700 K 15 ° NB 9.00 W 30000 15 ° 450 lm No
LED Performance LUGR Spotlight 9 W 3000 K 24 ° NB 9.00 W 30000 24 ° 470 lm No
LED Performance LUGR Spotlight 9 W 3000 K 24 ° OV 9.00 W 30000 24 ° 470 lm No
LED Performance LUGR Spotlight 9 W 3000 K 15 ° NB 9.00 W 30000 15 ° 470 lm No
LED Performance LUGR Spotlight 9 W 3000 K 36 ° NB 9.00 W 30000 36 ° 470 lm No
LED Performance LUGR Spotlight 9 W 3000 K 36 ° OV 9.00 W 30000 36 ° 470 lm No
LED Performance LUGR Spotlight 9 W 3000 K 15 ° OV 9.00 W 30000 15 ° 470 lm No
LED Performance LUGR Spotlight 9 W 2700 K 15 ° ADJ 9.00 W 30000 15 ° 480 lm No
LED Performance LUGR Spotlight 9 W 2700 K 36 ° ADJ 9.00 W 30000 36 ° 480 lm No
LED Performance LUGR Spotlight 9 W 2700 K 24 ° 9.00 W 30000 24 ° 480 lm No
LED Performance LUGR Spotlight 9 W 2700 K 36 ° 9.00 W 30000 36 ° 480 lm No
LED Performance LUGR Spotlight 9 W 2700 K 15 ° 9.00 W 30000 15 ° 480 lm No
LED Performance LUGR Spotlight 9 W 2700 K 24 ° ADJ 9.00 W 30000 24 ° 480 lm No
LED Performance LUGR Spotlight 9 W 4000 K 36 ° OV 9.00 W 30000 36 ° 485 lm No
LED Performance LUGR Spotlight 9 W 4000 K 36 ° NB 9.00 W 30000 36 ° 485 lm No
LED Performance LUGR Spotlight 9 W 4000 K 15 ° NB 9.00 W 30000 15 ° 485 lm No
LED Performance LUGR Spotlight 9 W 4000 K 24 ° OV 9.00 W 30000 24 ° 485 lm No
LED Performance LUGR Spotlight 9 W 4000 K 24 ° NB 9.00 W 30000 24 ° 485 lm No
LED Performance LUGR Spotlight 9 W 4000 K 15 ° OV 9.00 W 30000 15 ° 485 lm No
LED Performance LUGR Spotlight 9 W 3000 K 15 ° 9.00 W 30000 15 ° 500 lm No
LED Performance LUGR Spotlight 9 W 3000 K 24 ° 9.00 W 30000 24 ° 500 lm No
LED Performance LUGR Spotlight 9 W 3000 K 24 ° ADJ 9.00 W 30000 24 ° 500 lm No
LED Performance LUGR Spotlight 9 W 3000 K 36 ° ADJ 9.00 W 30000 36 ° 500 lm No


LED Performance LUGR Spotlight 7 W 2700 K 15 ° ADJ

Product benefits
  • High power COB LED provides high lumen output in compact housing
  • Low flicker light thanks to special electronic control gear
  • Good color rendering for the best product presentation
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 7.00 W
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Power factor λ 0.90
Protection class II
Operating mode External LED driver

Photometrical data

Luminous flux 385 lm
Luminous efficacy 55 lm/W
Color temperature 2700 K
Light color (designation) Warm White
Color rendering index Ra 90
Standard deviation of color matching ≤5 sdcm
Beam angle 15 °

Dimensions & Weight

Diameter 82.00 mm
Height 88.00 mm
Product weight 245.00 g

Materials & Colors

Product color Black
Housing color Black
Body material Aluminum
Cover material Polyamide (PA)|Polycarbonate (PC)
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -20…+40 °C
Temperature range at storage -20…+70 °C
Type of connection Cable, 2-pole
Type of protection IP20
Dimmable No
Mounting type Recessed
Mounting location Ceiling
Application environment Indoor
Mounting diameter 75,0 mm
Mounting depth > 140 mm

Lifespan

Lifespan L70/B50 at 25 °C 30000 h 1)
Number of switching cycles 30000

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Certificates & Standards

Replaceable light source (EPREL) Not replaceable

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • High power COB LED provides high lumen output in compact housing
  • Low flicker light thanks to special electronic control gear
  • Good color rendering for the best product presentation
Areas of application
  • Hospitality
  • Hotels, restaurants
  • Shops, supermarkets
Product features
  • Surface ring in four versions available: downright, adjustable, narrow beam, oval
  • Follows the unified LEDVANCE design language (SCALE design)
  • Available with color temperature 4000 K
  • Initial color consistency: < 5 SDCM
  • Type of protection: IP20
  • Lifetime (L70/B50): up to 30,000 h
  • Color rendering index Ra: > 90
  • Power factor: > 0.9
  • CCC marked, CB test certificate
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075324770 Folding box
1		 115 mm x 115 mm x 110 mm 317.00 g 1.45 dm³
4058075324787 Shipping box
40		 595 mm x 480 mm x 240 mm 14080.00 g 68.54 dm³
Product image: white background, upright
LDPFM LUGR SPOT AD 5/7 /9/12W JPG (1.36 MB)
Product line drawing with numbers
LDPFM LUGR SPOT AD 5/7 /9W SVG (105.37 KB)
