Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED ECO STREETLIGHT 30 W 3000 K | 30.00 W | 100000 | 75 ° x 135 ° | 2850 lm | No |
| LED ECO STREETLIGHT 30 W 4000 K | 30.00 W | 100000 | 75 ° x 135 ° | 3000 lm | No |
| LED ECO STREETLIGHT 30 W 6500 K | 30.00 W | 100000 | 75 ° x 135 ° | 3000 lm | No |
| LED ECO STREETLIGHT 30 W 3000 K HE | 30.00 W | 100000 | 75 ° x 135 ° | 3450 lm | No |
| LED ECO STREETLIGHT 30 W 4000 K HE | 30.00 W | 100000 | 75 ° x 135 ° | 3600 lm | No |
| LED ECO STREETLIGHT 30 W 6500 K HE | 30.00 W | 100000 | 75 ° x 135 ° | 3600 lm | No |
| LED ECO STREETLIGHT 45 W 3000 K HE | 45.00 W | 100000 | 75 ° x 135 ° | 5175 lm | No |
| LED ECO STREETLIGHT 45 W 4000 K HE | 45.00 W | 100000 | 75 ° x 135 ° | 5400 lm | No |
| LED ECO STREETLIGHT 45 W 6500 K HE | 45.00 W | 100000 | 75 ° x 135 ° | 5400 lm | No |
| LED ECO STREETLIGHT 50 W 3000 K | 50.00 W | 100000 | 75 ° x 135 ° | 4750 lm | No |
| LED ECO STREETLIGHT 50 W 4000 K | 50.00 W | 100000 | 75 ° x 135 ° | 5000 lm | No |
| LED ECO STREETLIGHT 50 W 6500 K | 50.00 W | 100000 | 75 ° x 135 ° | 5000 lm | No |
| LED ECO STREETLIGHT 60 W 3000 K HE | 60.00 W | 100000 | 75 ° x 135 ° | 7130 lm | No |
| LED ECO STREETLIGHT 60 W 4000 K HE | 60.00 W | 100000 | 75 ° x 135 ° | 7200 lm | No |
| LED ECO STREETLIGHT 60 W 6500 K HE | 60.00 W | 100000 | 75 ° x 135 ° | 7200 lm | No |
| LED ECO STREETLIGHT 70 W 3000 K | 70.00 W | 100000 | 75 ° x 135 ° | 6650 lm | No |
| LED ECO STREETLIGHT 70 W 4000 K | 70.00 W | 100000 | 75 ° x 135 ° | 7000 lm | No |
| LED ECO STREETLIGHT 70 W 6500 K | 70.00 W | 100000 | 75 ° x 135 ° | 7000 lm | No |
| Nominal wattage | 30.00 W |
| Nominal voltage | 100…240 V |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.90 |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 2850 lm |
| Luminous efficacy | 95 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | 80 |
| Standard deviation of color matching | 5 sdcm |
| Beam angle | 75 ° x 135 ° |
| Length | 325.00 mm |
| Height | 77.00 mm |
| Width | 121.00 mm |
| Product weight | 961.00 g |
| Cable length | 500 mm |
| Product color | Gray |
| Housing color | Gray |
| Body material | Aluminum|Polycarbonate (PC) |
| Cover material | Polycarbonate (PC) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -30…+50 °C |
| Temperature range at storage | -40…+70 °C |
| Type of connection | Cable, 3-pole |
| Type of protection | IP66 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | No |
| Mounting type | Standing |
| Mounting location | Pole |
| Application environment | Outdoor |
| LED module replaceable | Not replaceable |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075278899 | Folding box 1 |
366 mm x 94 mm x 168 mm | 903.00 g | 5.78 dm³ |
| 4058075278905 | Shipping box 10 |
495 mm x 380 mm x 355 mm | 10228.00 g | 66.78 dm³ |
