Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
---|---|---|---|---|---|
SF CIRCULAR 400 24 W 3000 K IP44 WT | 24.00 W | 100000 | 120 ° | 1920 lm | No |
SF CIRCULAR 400 24 W 4000 K IP44 WT | 24.00 W | 100000 | 120 ° | 1920 lm | No |
Nominal wattage | 24.00 W |
Nominal voltage | 220…240 V |
Mains frequency | 50…60 Hz |
Nominal current | 190 mA |
Inrush current | 15.0 A |
Inrush current time Th50 | 200 µs |
Max. number of luminaires per miniature circuit breaker B16 | 30 |
Max. number of luminaires per miniature circuit breaker C10 | 25 |
Max. number of luminaires per miniature circuit breaker C16 | 41 |
Power factor λ | > 0.5 |
Total harmonic distortion | < 120 % |
Protection class | I |
Operating mode | Integrated LED driver |
Luminous flux | 1920 lm |
Luminous efficacy | 80 lm/W |
Color temperature | 3000 K |
Light color (designation) | Warm White |
Color rendering index Ra | > 80 |
Standard deviation of color matching | ≤5 sdcm |
Low flicker | Yes |
Photobiological safety group acc. to EN62778 | RG0 |
Beam angle | 120 ° |
Diameter | 400.00 mm |
Height | 120.00 mm |
Product weight | 708.00 g |
Product color | White |
Housing color | White |
Body material | Steel |
Cover material | Polymethylmethacrylate (PMMA) |
Light emitting surface material | PMMA |
Glow Wire Test according to IEC 60695-2-12 | 650 °C |
Ambient temperature range | -20…+40 °C |
Temperature range at storage | -25…+70 °C |
Type of connection | Screw terminal, 3-Pole |
Type of protection | IP44 |
Protection class IK (shock resistance) | IK03 |
Dimmable | No |
Mounting type | Surface |
Mounting location | Ceiling, Wall |
Application environment | Indoor |
Replaceable light source (EPREL) | Not replaceable |
Lifespan L70/B50 at 25 °C | 30000 h 1) |
Lifespan L80/B10 at 25 °C | 22000 h 1) |
Lifespan L90/B10 at 25 °C | 15000 h |
Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Output current | 172 mA |
Standards | CE, CB, TÜV SÜD, EAC |
Ball shot safe | No |
Minimum rate of recycled material in packaging | 80 % 1) |
Minimum percentage of recycled content in the product | 0 % 1) |
Product recyclability | Mostly recyclable product 1) |
Packaging recyclability | Mostly recyclable packaging 1) |
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4058075080058 | Folding box 1 |
130 mm x 440 mm x 440 mm | 1090.00 g | 25.17 dm³ |
4058075080065 | Shipping box 5 |
665 mm x 455 mm x 460 mm | 6756.00 g | 139.18 dm³ |
EAN | SEG number | STK number | EFO number | ELDAS number |
---|---|---|---|---|
4058075080058 | 7504781 | 4110716 | 3241042 | 941000440 |
