Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED WALL WASHER 9 W 20 ° x 45 ° 500 mm RGB | 9.00 W | 30000 | 20 ° x 45 ° | 135 lm | Yes |
| LED WALL WASHER 9 W 45 ° 500 mm RGB | 9.00 W | 30000 | 45 ° | 162 lm | Yes |
| LED WALL WASHER 12 W 20 ° x 45 ° 500 mm RGB | 12.00 W | 30000 | 20 ° x 45 ° | 180 lm | Yes |
| LED WALL WASHER 12 W 45 ° 500 mm RGB | 12.00 W | 30000 | 45 ° | 216 lm | Yes |
| LED WALL WASHER 18 W 20 ° x 45 ° 1000 mm RGB | 18.00 W | 30000 | 20 ° x 45 ° | 270 lm | Yes |
| LED WALL WASHER 18 W 20 ° x 45 ° 500 mm RGB | 18.00 W | 30000 | 20 ° x 45 ° | 270 lm | Yes |
| LED WALL WASHER 18 W 45 ° 500 mm RGB | 18.00 W | 30000 | 45 ° | 324 lm | Yes |
| LED WALL WASHER 18 W 45 ° 1000 mm RGB | 18.00 W | 30000 | 45 ° | 324 lm | Yes |
| LED WALL WASHER 24 W 20 ° x 45 ° 1000 mm RGB | 24.00 W | 30000 | 20 ° x 45 ° | 360 lm | Yes |
| LED WALL WASHER 24 W 20 ° x 45 ° 500 mm RGB | 24.00 W | 30000 | 20 ° x 45 ° | 360 lm | Yes |
| LED WALL WASHER 24 W 45 ° 1000 mm RGB | 24.00 W | 30000 | 45 ° | 432 lm | Yes |
| LED WALL WASHER 24 W 45 ° 500 mm RGB | 24.00 W | 30000 | 45 ° | 432 lm | Yes |
| LED WALL WASHER 36 W 20 ° x 45 ° RGB | 36.00 W | 30000 | 20 ° x 45 ° | 540 lm | Yes |
| LED WALL WASHER 36 W 20 ° x 45 ° 500 mm RGB | 36.00 W | 30000 | 20 ° x 45 ° | 540 lm | Yes |
| LED WALL WASHER 36 W 45 ° 1000 mm RGB | 36.00 W | 30000 | 45 ° | 648 lm | Yes |
| LED WALL WASHER 36 W 45 ° 500 mm RGB | 36.00 W | 30000 | 45 ° | 648 lm | Yes |
| LED WALL WASHER 48 W 20 ° x 45 ° 1000 mm RGB | 48.00 W | 30000 | 20 ° x 45 ° | 720 lm | Yes |
| LED WALL WASHER 48 W 45 ° 1000 mm RGB | 48.00 W | 30000 | 45 ° | 864 lm | Yes |
| LED WALL WASHER 72 W 20 ° x 45 ° 1000 mm RGB | 72.00 W | 30000 | 20 ° x 45 ° | 1080 lm | Yes |
| Nominal wattage | 9.00 W |
| Nominal voltage | 24 V |
| Nominal current | 375.000 mA |
| Protection class | III |
| Luminous flux | 135 lm |
| Luminous efficacy | 15 lm/W |
| Light color (designation) | RGB |
| Standard deviation of color matching | ≤5 sdcm |
| Beam angle | 20 ° x 45 ° |
| Length | 500.00 mm |
| Height | 56.00 mm |
| Width | 38.00 mm |
| Product weight | 850.00 g |
| Cable length | 200 mm |
| Product color | Silver |
| Housing color | Silver |
| Body material | Glass|Aluminum |
| Cover material | CLEAR GLASS |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+50 °C |
| Temperature range at storage | -20…+70 °C |
| Type of connection | Plug, quick disconnect |
| Type of protection | IP66 |
| Protection class IK (shock resistance) | IK05 |
| Dimmable | Yes |
| Type of dimming | DMX |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Outdoor |
| LED module replaceable | Not replaceable |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 30000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Type of emergency operation test | None |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075334885 | Folding box 1 |
510 mm x 55 mm x 50 mm | 921.00 g | 1.40 dm³ |
| 4058075334892 | Shipping box 9 |
530 mm x 185 mm x 180 mm | 8791.00 g | 17.65 dm³ |
