Professional
UVC AIR TUBE

UVC AIR TUBE

Choose your product version



UVC AIR V70 WT UK

Product benefits
  • Proven technology – continuous air-treatment based on UV-C light
  • Effective – inactivates up to 99,9 % of viruses and bacteria
  • Quiet – extremely low-noise operation (ultra-silent)
  • Safe – no direct UV-C exposure, making it safe for humans and animals
  • Gentle – chemical-free operation and ozone-free lamp
  • Convenient – no filter, so it won’t need replacing
  • Versatile – Mount it wherever you want
  • Quality-built – Made in Germany, 3 years warranty
  • Teamwork – perfect match of lamp and ECG
  • SCALE Design – great appearance, valuable materials and small size fits into every surrounding

PRODUCT DETAILS

Electrical data

Nominal wattage 65.00 W
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Nominal current 0.28 A
Power factor λ 0.90
Protection class I
Operating mode Integrated driver

Photometrical data

Photobiological safety group acc. to EN62778 RG0

UV & Air cleaning

Maximum disinfection volume flow 70 m³/h
UV radiated power 26 W
Average radiation dose 53 J/m
UV-C source lifetime 10000 h
Noise level in UV-C disinfection mode 38 dB

Dimensions & Weight

Length 1105.00 mm
Height 150.00 mm
Width 150.00 mm
Product weight 6500.00 g
Cable length 3000 mm

Materials & Colors

Product color White
Body material Aluminum
Cover material Aluminium
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range +15…+40 °C
Type of connection Plug type G (UK)
Type of protection IP20
Protection class IK (shock resistance) IK03
Dimmable No
Mounting type Surface
Mounting location Ceiling, Wall, Floor
Equipped/equippable with T8 UVC LAMP
With light source Yes

Lifespan

Number of switching cycles 50000

Certificates & Standards

Standards CE
Product benefits
  • Proven technology – continuous air-treatment based on UV-C light
  • Effective – inactivates up to 99,9 % of viruses and bacteria
  • Quiet – extremely low-noise operation (ultra-silent)
  • Safe – no direct UV-C exposure, making it safe for humans and animals
  • Gentle – chemical-free operation and ozone-free lamp
  • Convenient – no filter, so it won’t need replacing
  • Versatile – Mount it wherever you want
  • Quality-built – Made in Germany, 3 years warranty
  • Teamwork – perfect match of lamp and ECG
  • SCALE Design – great appearance, valuable materials and small size fits into every surrounding
Areas of application
  • Wherever people meet in limited space, over a longer time period and low fresh Air-exchange
  • Offices, conference rooms
  • Classroom and education
  • Doctor´s office, especially waiting room
  • Retail and small shops
  • Restaurant
  • Elderly care
  • Reception areas and foyers
Product features
  • Clean air delivery rate of 70 m³/h with two low-noise fans
  • Recommended room size per device: max. 20 m² at a ceiling height of 2,5 m
  • Noise < 38dB
  • With 3 m cable and plug, on-off switch integrated in the front
  • Material: aluminum housing (white RAL9016, powder-coated), end-caps in anodized-aluminum
  • Lifetime: lamp up to 10.000 h
  • Mounting accessories must be ordered separately: pendant kit, wall mount, horizontal stand, vertical stand
  • UV-C spectrum: effective peak wavelength of 254 nm
  • Including UV-C lamp: 1 x LEDVANCE UVC T8 55W G13
  • Including lamp-ECG: OSRAM QTP OPTIMAL 1x54-58W
  • Dimensions: 150 × 150 × 1105 mm (H × W × L)
Equipment / Accessories
  • Mounting accessories available separately
References / Links
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075674363 Shipping box
1
255 mm x 1,160 mm x 242 mm 7197.00 g 71.58 dm³
