Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| DULUX F 18 W/830 2G10 | 2G10 | 18 W | 58 V | 13000 h | 1100 lm | Yes |
| DULUX F 18 W/840 2G10 | 2G10 | 18 W | 58 V | 13000 h | 1100 lm | Yes |
| DULUX F 24 W/830 2G10 | 2G10 | 24 W | 87 V | 13000 h | 1700 lm | Yes |
| DULUX F 24 W/840 2G10 | 2G10 | 24 W | 87 V | 13000 h | 1700 lm | Yes |
| DULUX F 36 W/827 2G10 | 2G10 | 36 W | 106 V | 13000 h | 2800 lm | Yes |
| DULUX F 36 W/830 2G10 | 2G10 | 36 W | 106 V | 13000 h | 2800 lm | Yes |
| DULUX F 36 W/840 2G10 | 2G10 | 36 W | 106 V | 13000 h | 2800 lm | Yes |
| Nominal wattage | 24 W |
| Construction wattage | 24.00 W |
| Nominal voltage | 87 V |
| Nominal current | 0.34 A |
| Luminous flux | 1700 lm |
| Luminous efficacy | 71 lm/W |
| Light color (designation) | LUMILUX Cool White |
| Color temperature | 4000 K |
| Color rendering index Ra | ≥80 |
| Light color | 840 |
| Rated LLMF at 2,000 h | 0.90 |
| Rated LLMF at 4,000 h | 0.86 |
| Rated LLMF at 6,000 h | 0.83 |
| Rated LLMF at 8,000 h | 0.81 |
| Rated LLMF at 12,000 h | 0.77 |
| Overall length | 170.00 mm |
| Length with base excl. base pins/connection | 162 mm |
| Diameter | 16.30 mm |
| Tube diameter | 17,5 mm |
| Product weight | 85.84 g |
| Ambient temperature range | -5…+40 °C |
| Service life | 9000 h 1) |
| Rated lamp survival factor at 2,000 h | 0.99 |
| Rated lamp survival factor at 4,000 h | 0.99 |
| Rated lamp survival factor at 6,000 h | 0.99 |
| Rated lamp survival factor at 8,000 h | 0.95 |
| Rated lamp survival factor at 12,000 h | 0.64 |
| Lifespan B50 | 13000 h |
1) With preheat ECG
| Base (standard designation) | 2G10 |
| Mercury content | 2.5 mg |
| Dimmable | Yes |
| Energy efficiency class | G |
| Energy consumption | 26.00 kWh/1000h |
| ILCOS | FSD-24/840-E-2G10-90/165 |
| Order reference | DULUX F 24W/840 |
| Lighting technology used | CFLNI |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | 2G10 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 170.00 mm |
| Height | 16.30 mm |
| Width | 16.30 mm |
| Chromaticity coordinate x | 0,380 |
| Chromaticity coordinate y | 0,380 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546528 |
| Model number | AC34302 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300333588 | Folding box 1 |
27 mm x 86 mm x 184 mm | 119.80 g | 0.43 dm³ |
| 4050300333595 | Shipping box 10 |
280 mm x 100 mm x 190 mm | 1319.00 g | 5.32 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4050300333588 | 8330642 | 4934019 | 3820444 | 946195120 |
