Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| HQI-TS 70 W/WDL | RX7s | 70 W | 98 V | 12000 h | 5925 lm | No |
| HQI-TS 70 W/NDL | RX7s | 70 W | 93 V | 12000 h | 6100 lm | No |
| HQI-TS 70 W/D | RX7s | 70 W | 92 V | 12000 h | 6200 lm | No |
| HQI-TS 150 W/WDL | RX7s-24 | 150 W | 95 V | 12000 h | 12000 lm | No |
| HQI-TS 150 W/NDL | RX7s-24 | 150 W | 93 V | 12000 h | 12500 lm | No |
| HQI-TS 150 W/D | RX7s-24 | 150 W | 100 V | 12000 h | 13000 lm | No |
| Nominal wattage | 70 W |
| Construction wattage | 81.20 W |
| Nominal voltage | 98 V |
| Ignition voltage | 13.3 kVp 1) |
| Operating mode | Conventional control gear (CCG) and ignitor, Electronic control gear (ECG) |
| Nominal current | 0.95 A |
| PFC capacitor at 50 Hz | 12 µF |
1) Minimum / Maximum
| Luminous flux | 5925 lm |
| Luminous efficacy | 73 lm/W |
| Color temperature | 3300 K |
| Color rendering index Ra | ≤ 67 |
| Light color | 633 |
| Rated LLMF at 2,000 h | 0.68 |
| Rated LLMF at 4,000 h | 0.64 |
| Rated LLMF at 6,000 h | 0.56 |
| Rated LLMF at 8,000 h | 0.50 |
| Rated LLMF at 12,000 h | 0.45 |
| UV protection | Yes |
| Overall length | 117.00 mm |
| Light center length (LCL) | 57,0 mm |
| Diameter | 19,0 mm |
| Product weight | 15.00 g |
| Maximum permitted outer bulb temperature | 500 °C |
| Maximum permitted pinch temperature | 350 °C |
| Rated lamp survival factor at 2,000 h | 0.95 |
| Rated lamp survival factor at 4,000 h | 0.90 |
| Rated lamp survival factor at 6,000 h | 0.85 |
| Rated lamp survival factor at 8,000 h | 0.80 |
| Rated lamp survival factor at 12,000 h | 0.50 |
| Lifespan B50 | 12000 h |
| Base (standard designation) | RX7s |
| Mercury content | 12.6 mg |
| Design / version | Clear |
| Dimmable | No |
| Burning position | P45 |
| Enclosed luminaire required | Yes |
| Hot restart | Yes |
| Energy efficiency class | G |
| Energy consumption | 82.00 kWh/1000h |
| ILCOS | MD/UB-70/730-H/E/SL-RX7s-19/117/H |
| Order reference | HQI-TS 70W/WDL/ |
| Lighting technology used | MH |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | RX7s |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | SECOND |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 117.00 mm |
| Height | 19,0 mm |
| Width | 19,0 mm |
| Chromaticity coordinate x | 0,427 |
| Chromaticity coordinate y | 0,398 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546549 |
| Model number | AC34323 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4008321678300 | Folding box 1 |
35 mm x 35 mm x 121 mm | 28.00 g | 0.15 dm³ |
| 4008321678317 | Shipping box 12 |
149 mm x 116 mm x 135 mm | 386.00 g | 2.33 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4008321678300 | 8333206 | 4834739 | 3861028 | 948885000 |
