Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Dimmable |
|---|---|---|---|---|---|---|
| HQI-TS 70 W/WDL | RX7s | 70 W | 98 V | 12000 h | 5925 lm | No |
| HQI-TS 70 W/NDL | RX7s | 70 W | 93 V | 12000 h | 6100 lm | No |
| HQI-TS 70 W/D | RX7s | 70 W | 92 V | 12000 h | 6200 lm | No |
| HQI-TS 150 W/WDL | RX7s-24 | 150 W | 95 V | 12000 h | 12000 lm | No |
| HQI-TS 150 W/NDL | RX7s-24 | 150 W | 93 V | 12000 h | 12500 lm | No |
| HQI-TS 150 W/D | RX7s-24 | 150 W | 100 V | 12000 h | 13000 lm | No |
| Nominal wattage | 150 W |
| Construction wattage | 156.60 W |
| Nominal voltage | 100 V |
| Ignition voltage | 13.3 kVp 1) |
| Operating mode | Conventional control gear (CCG) and ignitor, Electronic control gear (ECG) |
| Nominal current | 1.8 A |
| PFC capacitor at 50 Hz | 20 µF |
1) Minimum / Maximum
| Luminous flux | 13000 lm |
| Luminous efficacy | 83 lm/W |
| Color temperature | 5450 K |
| Color rendering index Ra | ≤ 81 |
| Light color | 854 |
| Rated LLMF at 2,000 h | 0.86 |
| Rated LLMF at 4,000 h | 0.84 |
| Rated LLMF at 6,000 h | 0.77 |
| Rated LLMF at 8,000 h | 0.74 |
| Rated LLMF at 12,000 h | 0.70 |
| UV protection | Yes |
| Overall length | 135.00 mm |
| Light center length (LCL) | 66.00 mm |
| Diameter | 23 mm |
| Product weight | 22.00 g |
| Maximum permitted outer bulb temperature | 450 °C |
| Maximum permitted pinch temperature | 350 °C |
| Rated lamp survival factor at 2,000 h | 0.95 |
| Rated lamp survival factor at 4,000 h | 0.90 |
| Rated lamp survival factor at 6,000 h | 0.85 |
| Rated lamp survival factor at 8,000 h | 0.80 |
| Rated lamp survival factor at 12,000 h | 0.50 |
| Lifespan B50 | 12000 h |
| Base (standard designation) | RX7s-24 |
| Mercury content | 13.0 mg |
| Design / version | Clear |
| Dimmable | No |
| Burning position | P45 |
| Enclosed luminaire required | Yes |
| Hot restart | Yes |
| Energy efficiency class | G |
| Energy consumption | 157.00 kWh/1000h |
| ILCOS | MD/UB-150/856-H/E/SL-RX7s=24-23/135/H |
| Order reference | HQI-TS 150W/D/E |
| Lighting technology used | MH |
| Non-directional or directional | NDLS |
| Mains or non-mains | NMLS |
| Light source cap-type (or other electric interface) | RX7s-24 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | SECOND |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Claim of equivalent power | No |
| Length | 135.00 mm |
| Height | 23 mm |
| Width | 23 mm |
| Chromaticity coordinate x | 0,335 |
| Chromaticity coordinate y | 0,348 |
| Beam angle correspondence | SPHERE_360 |
| EPREL ID | 546550 |
| Model number | AC34324 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4008321678409 | Folding box 1 |
35 mm x 35 mm x 141 mm | 32.00 g | 0.17 dm³ |
| 4008321678416 | Shipping box 12 |
149 mm x 116 mm x 154 mm | 498.00 g | 2.66 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4008321678409 | 8333222 | 4834753 | 3861018 | 948885220 |
