Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED VALUE CLAS P FIL 4 W/2700 K B22d GEN2 | B22d | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/2700 K E14 FR GEN2 | E14 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/2700 K E14 GEN2 | E14 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/2700 K E27 GEN2 | E27 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/2700 K E27 GEN2 | E27 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/4000 K E14 GEN2 | E14 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/4000 K E14 CL | E14 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| LED VALUE CLAS P FIL 4 W/4000 K E14 | E14 | 4 W | 220…240 V | 15000 h | 470 lm | 40 W | 300 ° | No |
| Nominal wattage | 4 W |
| Construction wattage | 4.00 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 40 W |
| Nominal current | 35 mA |
| Type of current | AC |
| Operating frequency | 50…60 Hz |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.40 |
| Luminous flux | 470 lm |
| Nominal useful luminous flux 90° | 470 lm |
| Luminous efficacy | 117 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Cool White |
| Color temperature | 4000 K |
| Color rendering index Ra | ≥80 |
| Light color | 840 |
| Standard deviation of color matching | ≤6 sdcm |
| Beam angle | 300 ° |
| Starting time | < 0.5 s |
| Overall length | 78.00 mm |
| Diameter | 45.00 mm |
| Maximum diameter | 45 mm |
| Product weight | 13.00 g |
| Ambient temperature range | -20…+40 °C |
| Number of switching cycles | 100000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Base (standard designation) | E14 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Design / version | Frosted |
| Product remark | All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | No |
| Type of protection | IP20 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Order reference | LV CLP 4W/840 2 |
| Light source cap-type (or other electric interface) | E14 |
| Standby power | 0 W |
| Length | 78.00 mm |
| Height | 45.00 mm |
| Width | 45.00 mm |
| EPREL ID | 1403405,523181 |
| Model number | AC24331,AC32370 |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075267800 | Folding box 1 |
51 mm x 51 mm x 107 mm | 27.00 g | 0.28 dm³ |
| 4058075509245 | Shipping box 10 |
266 mm x 109 mm x 121 mm | 396.00 g | 3.51 dm³ |
| 4058075751040 | Shipping box 10 |
266 mm x 109 mm x 121 mm | 376.00 g | 3.51 dm³ |
| 4099854260148 | Shipping box 10 |
266 mm x 109 mm x 121 mm | 396.00 g | 3.51 dm³ |
