Choose your product version
| Product description | Nominal wattage | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|
| LED PFM DL 6.30 W 3000 K G2S | 6.30 W | 65 ° | 817 lm | No |
| LED PFM DL 6.30 W 4000 K G2S | 6.30 W | 65 ° | 860 lm | No |
| LED PFM DL 6.30 W 6500 K G2S | 6.30 W | 65 ° | 860 lm | No |
| LED PFM DL 12.50 W 3000 K G2S | 12.50 W | 65 ° | 1680 lm | No |
| LED PFM DL 12.50 W 4000 K G2S | 12.50 W | 65 ° | 1770 lm | No |
| LED PFM DL 12.50 W 6500 K G2S | 12.50 W | 65 ° | 1770 lm | No |
| LED PFM DL 17.50 W 3000 K G2S | 17.50 W | 65 ° | 2375 lm | No |
| LED PFM DL 17.50 W 4000 K G2S | 17.50 W | 65 ° | 2500 lm | No |
| LED PFM DL 17.50 W 6500 K G2S | 17.50 W | 65 ° | 2500 lm | No |
| LED PFM DL 26.00 W 3000 K G2S | 26.00 W | 65 ° | 3250 lm | No |
| LED PFM DL 26.00 W 4000 K G2S | 26.00 W | 65 ° | 3500 lm | No |
| LED PFM DL 26.00 W 6500 K G2S | 26.00 W | 65 ° | 3500 lm | No |
| Nominal wattage | 6.30 W |
| Nominal voltage | 26,5 V |
| Nominal current | 270.000 mA |
| Power factor λ | > 0.90 |
| Protection class | III |
| Operating mode | External LED driver |
| Luminous flux | 817 lm |
| Luminous efficacy | 129 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | 80 |
| Standard deviation of color matching | < 5 sdcm |
| Beam angle | 65 ° |
| UGR | < 19 |
| Diameter | 112.00 mm |
| Height | 50.00 mm |
| Product weight | 258.00 g |
| Product color | White |
| Housing color | White |
| Body material | Aluminum |
| Cover material | Polymethylmethacrylate (PMMA) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+45 °C |
| Temperature range at storage | -20…+70 °C |
| Type of connection | Cable, 2-pole |
| Type of protection | IP54/IP20 |
| Dimmable | No |
| Mounting type | Recessed |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Mounting diameter | 100.0…110.0 mm |
| Mounting depth | > 30 mm |
| LED module replaceable | Not replaceable |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075427501 | Folding box 1 |
174 mm x 74 mm x 177 mm | 375.00 g | 2.28 dm³ |
| 4058075427518 | Shipping box 30 |
543 mm x 390 mm x 385 mm | 12382.00 g | 81.53 dm³ |
