Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LDVAL FL 10W 830 | 10.00 W | 30000 | 100 ° | 900 lm | No |
| LDVAL FL 10W 840 | 10.00 W | 30000 | 100 ° | 1000 lm | No |
| LDVAL FL 10W 865 | 10.00 W | 30000 | 100 ° | 1000 lm | No |
| LDVAL FL 20W 830 | 20.00 W | 30000 | 100 ° | 1800 lm | No |
| LDVAL FL 20W 840 | 20.00 W | 30000 | 100 ° | 2000 lm | No |
| LDVAL FL 20W 865 | 20.00 W | 30000 | 100 ° | 2000 lm | No |
| LDVAL FL 30W 830 | 30.00 W | 30000 | 100 ° | 2700 lm | No |
| LDVAL FL 30W 840 | 30.00 W | 30000 | 100 ° | 3000 lm | No |
| LDVAL FL 30W 865 | 30.00 W | 30000 | 100 ° | 3000 lm | No |
| LDVAL FL 50W 830 | 50.00 W | 30000 | 100 ° | 4500 lm | No |
| LDVAL FL 50W 840 | 50.00 W | 30000 | 100 ° | 5000 lm | No |
| LDVAL FL 50W 865 | 50.00 W | 30000 | 100 ° | 5000 lm | No |
| LDVAL FL 100W 830 | 100.00 W | 30000 | 110 ° | 9000 lm | No |
| LDVAL FL 100W 840 | 100.00 W | 30000 | 110 ° | 10000 lm | No |
| LDVAL FL 100W 865 | 100.00 W | 30000 | 110 ° | 10000 lm | No |
| LDVAL FL 150W 830 | 150.00 W | 30000 | 110 ° | 13500 lm | No |
| LDVAL FL 150W 840 | 150.00 W | 30000 | 110 ° | 15000 lm | No |
| LDVAL FL 150W 865 | 150.00 W | 30000 | 110 ° | 15000 lm | No |
| LDVAL FL 200W 830 | 200.00 W | 30000 | 110 ° | 18000 lm | No |
| LDVAL FL 200W 840 | 200.00 W | 30000 | 110 ° | 20000 lm | No |
| LDVAL FL 200W 865 | 200.00 W | 30000 | 110 ° | 20000 lm | No |
| Nominal wattage | 200.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 962.000 mA |
| Inrush current |
|
| Max. number of luminaires per miniature circuit breaker B16 | - |
| Max. number of luminaires per miniature circuit breaker C16 | - |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 20 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 20000 lm |
| Luminous efficacy | 100 lm/W |
| Color temperature | 6500 K |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 5 sdcm |
| Luminous intensity | 6790 cd |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 110 ° |
| Length | 340.00 mm |
| Height | 55.00 mm |
| Width | 300.00 mm |
| Product weight | 2520.00 g |
| Cable length | 500 mm |
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Cover material | Glass |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -30…+50 °C |
| Temperature range at storage | -40…+70 °C |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK06 |
| Dimmable | No |
| Mounting type | Surface |
| LED module replaceable | Not replaceable |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Lifespan L80/B10 at 25 °C | 24000 h 1) |
| Lifespan L90/B10 at 25 °C | 18000 h |
| Number of switching cycles | 30000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CB, RoHS, EMC |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075589575 | Folding box 1 |
93 mm x 383 mm x 344 mm | 2743.00 g | 12.25 dm³ |
| 4058075589582 | Shipping box 2 |
392 mm x 194 mm x 356 mm | 5862.00 g | 27.07 dm³ |
