Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| HIGH BAY VALUE 100 W 4000 K 100 DEG IP65 BK | 100.00 W | 50000 | 100 ° | 10000 lm | No |
| HIGH BAY VALUE 100 W 6500 K 100 DEG IP65 BK | 100.00 W | 50000 | 100 ° | 10000 lm | No |
| HIGH BAY VALUE 150 W 4000 K 100 DEG IP65 BK | 150.00 W | 50000 | 100 ° | 16000 lm | No |
| HIGH BAY VALUE 150 W 6500 K 100 DEG IP65 BK | 150.00 W | 50000 | 100 ° | 16000 lm | No |
| HIGH BAY VALUE 200 W 4000 K 100 DEG IP65 BK | 200.00 W | 50000 | 100 ° | 20000 lm | No |
| HIGH BAY VALUE 200 W 6500 K 100 DEG IP65 BK | 200.00 W | 50000 | 100 ° | 20000 lm | No |
| Nominal wattage | 200.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 910 mA |
| Inrush current | 10.3 A |
| Inrush current time Th50 | 3.66 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 14 |
| Max. number of luminaires per miniature circuit breaker C10 | 8 |
| Max. number of luminaires per miniature circuit breaker C16 | 14 |
| Power factor λ | ≥0.90 |
| Total harmonic distortion | < 20 % |
| Protection class | I |
| Operating mode | Mains voltage |
| Luminous flux | 20000 lm |
| Luminous efficacy | 100 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 5 sdcm |
| Photobiological safety group acc. to EN62778 | RG1 |
| Photobiological safety group acc. to EN62471 | RG1 |
| Beam angle | 100 ° |
| Diameter | 310.00 mm |
| Height | 51.40 mm |
| Product weight | 2260.00 g |
| Cable length | 500 mm |
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Cover material | Tempered glass |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+50 °C |
| Type of connection | Cable, 3-pole |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK06 |
| Dimmable | No |
| Mounting type | Suspended/Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| LED module replaceable | Not replaceable |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Lifespan L80/B10 at 25 °C | 32000 h 1) |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, CB, EAC |
| Luminaire with limited surface temperature, "D sign" | Yes |
| Ball shot safe | No |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075408456 | Shipping box 1 |
337 mm x 337 mm x 89 mm | 2547.00 g | 10.11 dm³ |
| EAN | STK number | EFO number |
|---|---|---|
| 4058075408456 | 4315601 | 3242453 |
