Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| PANEL 1200 DALI 40 W 4000 K WT | 40.00 W | 25000 | 120 ° | 4000 lm | Yes |
| Nominal wattage | 40.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 1200.000 mA |
| Power factor λ | > 0.90 |
| Total harmonic distortion | ≤ 20 % |
| Protection class | II |
| Operating mode | External LED driver |
| Luminous flux | 4000 lm |
| Luminous efficacy | 100 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | ≤6 sdcm |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 120 ° |
| Length | 1195.00 mm |
| Height | 10.50 mm |
| Width | 295.00 mm |
| Product weight | 3000.00 g |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polystyrene (PS) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -10…+45 °C |
| Type of connection | Screwless terminal, 5-Pole |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK06 |
| Dimmable | Yes |
| Type of dimming | DALI |
| Mounting type | Recessed/Suspended/Surface |
| Mounting location | Ceiling, Wall |
| Application environment | Indoor |
| Mounting length | 1175 mm |
| Mounting width | 275 mm |
| Mounting depth | 50,0 mm |
| Replaceable light source | No |
| Lifespan L70/B50 at 25 °C | 60000 h 1) |
| Lifespan L80/B10 at 25 °C | 40000 h 1) |
| Lifespan L90/B10 at 25 °C | 20000 h |
| Number of switching cycles | 25000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| ECG - Length | 150 mm |
| ECG - Width | 43 mm |
| ECG - Height | 30 mm |
| Standards | CE, CB, RoHS |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Additional info can be provided per individual request |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075041998 | Folding box 1 |
43 mm x 1,285 mm x 330 mm | 3718.00 g | 18.23 dm³ |
| 4058075042001 | Shipping box 4 |
1,324 mm x 346 mm x 200 mm | 14580.00 g | 91.62 dm³ |
| Product image | Product name | EAN |
|---|---|---|
|
EM CONVERSION BOX | 4058075237025 |
|
PANEL 1200x300 RECESSED MOUNT FRAME | 4058075472976 |
|
PANEL RECESSED MOUNT CLIPS VAL 4x | 4058075409859 |
|
PANEL 1200 Surface Mount Kit | 4058075108820 |
|
CONNECTOR BOX 5POLE L/N/PE/D+/D- 4x | 4058075473034 |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075041998 | 7014600 | 4295628 | 3241083 | 941331250 |
