Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| SPOT MULTI 3 x 30W 3000K FL WT/BK | 3*30 W | 50000 | 38 ° | 3*2700 lm | No |
| SPOT MULTI 3 x 30W 4000K FL WT/BK | 3*30 W | 50000 | 38 ° | 3*2700 lm | No |
| Nominal wattage | 3*30 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 450 mA |
| Inrush current | 69 A |
| Inrush current time Th50 | < 3.4 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 10 |
| Max. number of luminaires per miniature circuit breaker C10 | 8 |
| Max. number of luminaires per miniature circuit breaker C16 | 13 |
| Power factor λ | ≥0.90 |
| Total harmonic distortion | < 15 % |
| Protection class | II |
| Operating mode | External LED driver |
| Luminous flux | 3*2700 lm |
| Luminous efficacy | 90 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | ≤4 sdcm |
| Luminous intensity | - |
| Low flicker | Yes |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 38 ° |
| Length | 487.00 mm |
| Height | 135.00 mm |
| Width | 173.00 mm |
| Product weight | 3870.00 g |
| Product color | White |
| Housing color | White |
| Body material | Aluminum |
| Cover material | Polymethylmethacrylate (PMMA) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -10…+40 °C |
| Type of connection | Screw terminal, 2-Pole (L,N) |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Recessed |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Mounting length | 475 mm |
| Mounting width | 160 mm |
| Mounting depth | 250 mm |
| Adjustable | Yes |
| LED module replaceable | Not replaceable |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Lifespan L80/B10 at 25 °C | 45000 h 1) |
| Lifespan L90/B10 at 25 °C | 30000 h |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| ECG - Length | 113 mm |
| ECG - Width | 40 mm |
| ECG - Height | 25 mm |
| Standards | CE, CB, ENEC, TÜV SÜD, RoHS |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075114005 | Folding box 1 |
210 mm x 525 mm x 170 mm | 4050.00 g | 18.74 dm³ |
| 4058075114012 | Shipping box 2 |
535 mm x 220 mm x 400 mm | 16760.00 g | 47.08 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075114005 | 7451226 | 4231935 | 3201945 | 941400590 |
