Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| TR SP COMPACT D100 28 W 930 FL BK | 28.00 W | 100000 | 36 ° | 2200 lm | No |
| TR SP COMPACT D100 28 W 930 FL GY | 28.00 W | 100000 | 36 ° | 2200 lm | No |
| TR SP COMPACT D100 28 W 930 FL WT | 28.00 W | 100000 | 36 ° | 2200 lm | No |
| TR SP COMPACT D100 28 W 930 NFL BK | 28.00 W | 100000 | 25 ° | 2280 lm | No |
| TR SP COMPACT D100 28 W 930 NFL GY | 28.00 W | 100000 | 25 ° | 2280 lm | No |
| TR SP COMPACT D100 28 W 930 NFL WT | 28.00 W | 100000 | 25 ° | 2280 lm | No |
| TR SP COMPACT D100 28 W 940 FL BK | 28.00 W | 100000 | 36 ° | 2300 lm | No |
| TR SP COMPACT D100 28 W 940 FL GY | 28.00 W | 100000 | 36 ° | 2300 lm | No |
| TR SP COMPACT D100 28 W 940 FL WT | 28.00 W | 100000 | 36 ° | 2300 lm | No |
| TR SP COMPACT D100 28 W 940 NFL GY | 28.00 W | 100000 | 25 ° | 2380 lm | No |
| TR SP COMPACT D100 28 W 940 NFL WT | 28.00 W | 100000 | 25 ° | 2380 lm | No |
| TR SP COMPACT D100 28 W 940 NFL BK | 28.00 W | 100000 | 25 ° | 2380 lm | No |
| Nominal wattage | 28.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 120 mA |
| Inrush current |
|
| Inrush current time Th50 | < 500 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 25 |
| Max. number of luminaires per miniature circuit breaker C16 | 40 |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 20 % |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 2380 lm |
| Luminous efficacy | 85 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | 90 |
| Standard deviation of color matching | ≤3 sdcm |
| Luminous intensity | - |
| Low flicker | Yes |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 25 ° |
| Length | 260.00 mm |
| Height | 160.00 mm |
| Width | 33.00 mm |
| Product weight | 400.00 g |
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Cover material | Polymethylmethacrylate (PMMA) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+35 °C |
| Type of connection | Adapter, 3-phase |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Mounting track |
| Application environment | Indoor |
| Adjustable | Yes |
| LED module replaceable | Not replaceable |
| With light source | No |
| Lifespan L70/B50 at 25 °C | 80000 h 1) |
| Lifespan L80/B10 at 25 °C | 50000 h 1) |
| Lifespan L90/B10 at 25 °C | 35000 h |
| Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| ECG - Output voltage | 27…42 V |
| ECG - Output ripple current | < 3 % |
| Standards | CE, CB, ENEC, TÜV SÜD, EAC, RoHS |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075335967 | Folding box 1 |
114 mm x 114 mm x 264 mm | 513.00 g | 3.43 dm³ |
| 4058075335974 | Shipping box 4 |
239 mm x 239 mm x 280 mm | 2292.00 g | 15.99 dm³ |
| EAN | SEG number | STK number | ELDAS number |
|---|---|---|---|
| 4058075335967 | 7402583 | 4266657 | 941600480 |
