Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED ECO Downlight 7.00 W 3000 K GEN1 | 7.00 W | 15000 | 110 ° | 450 lm | No |
| LED ECO Downlight 7.00 W 4000 K GEN1 | 7.00 W | 15000 | 110 ° | 480 lm | No |
| LED ECO Downlight 7.00 W 6500 K GEN1 | 7.00 W | 15000 | 110 ° | 480 lm | No |
| LED ECO Downlight 10.00 W 3000 K GEN1 | 10.00 W | 15000 | 110 ° | 700 lm | No |
| LED ECO Downlight 10.00 W 4000 K GEN1 | 10.00 W | 15000 | 110 ° | 700 lm | No |
| LED ECO Downlight 10.00 W 6500 K GEN1 | 10.00 W | 15000 | 110 ° | 700 lm | No |
| LED ECO Downlight 12.50 W 3000 K GEN1 | 12.50 W | 15000 | 110 ° | 950 lm | No |
| LED ECO Downlight 12.50 W 4000 K GEN1 | 12.50 W | 15000 | 110 ° | 950 lm | No |
| LED ECO Downlight 12.50 W 6500 K GEN1 | 12.50 W | 15000 | 110 ° | 950 lm | No |
| LED ECO Downlight 15.00 W 3000 K GEN1 | 15.00 W | 15000 | 110 ° | 1100 lm | No |
| LED ECO Downlight 15.00 W 4000 K GEN1 | 15.00 W | 15000 | 110 ° | 1100 lm | No |
| LED ECO Downlight 15.00 W 6500 K GEN1 | 15.00 W | 15000 | 110 ° | 1100 lm | No |
| LED ECO Downlight 18.00 W 3000 K GEN1 | 18.00 W | 15000 | 110 ° | 1400 lm | No |
| LED ECO Downlight 18.00 W 4000 K GEN1 | 18.00 W | 15000 | 110 ° | 1400 lm | No |
| LED ECO Downlight 18.00 W 6500 K GEN1 | 18.00 W | 15000 | 110 ° | 1400 lm | No |
| Nominal wattage | 7.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 55.000 mA |
| Power factor λ | 0.50 |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 450 lm |
| Luminous efficacy | 64 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | 6 sdcm |
| Beam angle | 110 ° |
| Diameter | 92.00 mm |
| Height | 50.00 mm |
| Product weight | 52.00 g |
| Product color | White |
| Housing color | White |
| Body material | Plastic |
| Cover material | Polycarbonate (PC) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+70 °C |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Mounting diameter | 70.0…80.0 mm |
| Mounting depth | 100 mm |
| LED module replaceable | Not replaceable |
| Lifespan L70/B50 at 25 °C | 15000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075341692 | Folding box 1 |
93 mm x 56 mm x 93 mm | 112.00 g | 0.48 dm³ |
| 4058075341708 | Shipping box 40 |
485 mm x 240 mm x 205 mm | 5093.00 g | 23.86 dm³ |
