Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED ECO Downlight 7.00 W 3000 K GEN1 | 7.00 W | 15000 | 110 ° | 450 lm | No |
| LED ECO Downlight 7.00 W 4000 K GEN1 | 7.00 W | 15000 | 110 ° | 480 lm | No |
| LED ECO Downlight 7.00 W 6500 K GEN1 | 7.00 W | 15000 | 110 ° | 480 lm | No |
| LED ECO Downlight 10.00 W 3000 K GEN1 | 10.00 W | 15000 | 110 ° | 700 lm | No |
| LED ECO Downlight 10.00 W 4000 K GEN1 | 10.00 W | 15000 | 110 ° | 700 lm | No |
| LED ECO Downlight 10.00 W 6500 K GEN1 | 10.00 W | 15000 | 110 ° | 700 lm | No |
| LED ECO Downlight 12.50 W 3000 K GEN1 | 12.50 W | 15000 | 110 ° | 950 lm | No |
| LED ECO Downlight 12.50 W 4000 K GEN1 | 12.50 W | 15000 | 110 ° | 950 lm | No |
| LED ECO Downlight 12.50 W 6500 K GEN1 | 12.50 W | 15000 | 110 ° | 950 lm | No |
| LED ECO Downlight 15.00 W 3000 K GEN1 | 15.00 W | 15000 | 110 ° | 1100 lm | No |
| LED ECO Downlight 15.00 W 4000 K GEN1 | 15.00 W | 15000 | 110 ° | 1100 lm | No |
| LED ECO Downlight 15.00 W 6500 K GEN1 | 15.00 W | 15000 | 110 ° | 1100 lm | No |
| LED ECO Downlight 18.00 W 3000 K GEN1 | 18.00 W | 15000 | 110 ° | 1400 lm | No |
| LED ECO Downlight 18.00 W 4000 K GEN1 | 18.00 W | 15000 | 110 ° | 1400 lm | No |
| LED ECO Downlight 18.00 W 6500 K GEN1 | 18.00 W | 15000 | 110 ° | 1400 lm | No |
| Nominal wattage | 15.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 110.000 mA |
| Power factor λ | 0.50 |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 1100 lm |
| Luminous efficacy | 73 lm/W |
| Color temperature | 6500 K |
| Light color (designation) | Daylight |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | 6 sdcm |
| Beam angle | 110 ° |
| Diameter | 166.00 mm |
| Height | 54.00 mm |
| Product weight | 118.00 g |
| Product color | White |
| Housing color | White |
| Body material | Plastic |
| Cover material | Polycarbonate (PC) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+70 °C |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Mounting diameter | 140.0…160.0 mm |
| Mounting depth | 100 mm |
| Lifespan L70/B50 at 25 °C | 15000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Replaceable light source (EPREL) | Not replaceable |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075342071 | Folding box 1 |
170 mm x 66 mm x 170 mm | 191.00 g | 1.91 dm³ |
| 4058075342088 | Shipping box 20 |
355 mm x 355 mm x 360 mm | 4770.00 g | 45.37 dm³ |
