LED VALUE CLASSIC A FILAMENT

LED VALUE CLASSIC A FILAMENT

Choose your product version

4 W/2700 K B22d CL

4 W/2700 K E27 CL

4 W/2700 K E27

4 W/4000 K E27

4 W/4000 K E27 CL

6.5 W/2700 K B22d CL

6.5 W/2700 K B22d FR

6.5 W/2700 K E27

6.5 W/2700 K E27 CL

6.5 W/2700 K E27

6.5 W/2700 K E27

6.5 W/4000 K E27

6.5 W/4000 K E27

7 W/2700 K E27 FR

7.5 W/2700 K B22d CL

7.5 W/2700 K E27 CL

7.5 W/4000 K B22d CL

7.5 W/4000 K E27 CL

OVERVIEW

Product description	Base (standard designation)	Nominal wattage	Nominal voltage	Nominal lamp life time	Nominal luminous flux	Claimed equiv. conventional lamp power	Beam angle	Dimmable
LED VALUE CLAS A FIL 4 W/2700 K B22d CL	B22d	4 W	220…240 V	15000 h	470 lm	40 W	300 °	No
LED VALUE CLAS A FIL 4 W/2700 K E27 CL	E27	4 W	220…240 V	15000 h	470 lm	40 W	300 °	No
LED VALUE CLAS A FIL 4 W/2700 K E27	E27	4 W	220…240 V	15000 h	470 lm	40 W	300 °	No
LED VALUE CLAS A FIL 4 W/4000 K E27	E27	4 W	220…240 V	15000 h	470 lm	40 W	300 °	No
LED VALUE CLAS A FIL 4 W/4000 K E27 CL	E27	4 W	220…240 V	15000 h	470 lm	40 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/2700 K B22d CL	B22d	6.5 W	220…240 V	15000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/2700 K B22d FR	B22d	6.5 W	220…240 V	15000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/2700 K E27	E27	6.5 W	220…240 V	20000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/2700 K E27 CL	E27	6.5 W	220…240 V	15000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/2700 K E27	E27	6.5 W	220…240 V	20000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/2700 K E27	E27	6.5 W	220…240 V	20000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/4000 K E27	E27	6.5 W	220…240 V	15000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 6.5 W/4000 K E27	E27	6.5 W	220…240 V	15000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 7 W/2700 K E27 FR	E27	7 W	220…240 V	15000 h	806 lm	60 W	300 °	No
LED VALUE CLAS A FIL 7.5 W/2700 K B22d CL	B22d	7.5 W	220…240 V	10000 h	1055 lm	75 W	300 °	No
LED VALUE CLAS A FIL 7.5 W/2700 K E27 CL	E27	7.5 W	220…240 V	15000 h	1055 lm	75 W	300 °	No
LED VALUE CLAS A FIL 7.5 W/4000 K B22d CL	B22d	7.5 W	220…240 V	10000 h	1055 lm	75 W	300 °	No
LED VALUE CLAS A FIL 7.5 W/4000 K E27 CL	E27	7.5 W	220…240 V	15000 h	1055 lm	75 W	300 °	No

LED VALUE CLAS A FIL 4 W/2700 K B22d CL

Product benefits

Lamps with innovative LED "filament" technology
Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
Very low energy consumption
No UV and near-IR radiation in the light beam
Instant 100 % light, no warm-up time
Can be easily fitted instead of ordinary light bulbs
Lower thermal output (compared with the standard reference product)
Correct operation even at low temperatures

View all details

Product data sheet

PRODUCT DETAILS

Technical data

Electrical data

Nominal wattage	4 W
Construction wattage	4.00 W
Nominal voltage	220…240 V
Claimed equiv. conventional lamp power	40 W
Nominal current	35 mA
Type of current	AC
Operating frequency	50…60 Hz
Mains frequency	50…60 Hz
Power factor λ	> 0.40

Photometrical data

Luminous flux	470 lm
Nominal useful luminous flux 90°	470 lm
Luminous efficacy	117 lm/W
Lumen main.fact.at end of nom.life time	0.70
Light color (designation)	Warm White
Color temperature	2700 K
Color rendering index Ra	≥80
Light color	827
Standard deviation of color matching	≤6 sdcm

Light technical data

Beam angle	300 °
Starting time	< 0.5 s

Dimensions & Weight

Overall length	104.00 mm
Diameter	60.00 mm
Maximum diameter	60 mm
Product weight	31.00 g

Temperatures & operating conditions

Ambient temperature range

-20…+40 °C

Lifespan

Number of switching cycles	100000
Lumen maintenance at end of service lifetime	0.70

Additional product data

Base (standard designation)	B22d
Mercury content	0.0 mg
Mercury-free	Yes
Design / version	Clear
Product remark	All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Capabilities

Dimmable

No

Certificates & Standards

Type of protection

IP20

Country-specific categorizations

Order reference

LV CLA 4W/827 2

LOGISTICAL DATA

Temperature range at storage

-20…+80 °C

Energy labelling regulation data acc EU 2019/2015

Light source cap-type (or other electric interface)	B22d
Length	104.00 mm
Height	60.00 mm
Width	60.00 mm
EPREL ID	1403179,523220
Model number	AC24355,AC32413

Product description

Product benefits

Lamps with innovative LED "filament" technology
Design, dimensions, luminous flux comparable to an incandescent or halogen lamp
Very low energy consumption
No UV and near-IR radiation in the light beam
Instant 100 % light, no warm-up time
Can be easily fitted instead of ordinary light bulbs
Lower thermal output (compared with the standard reference product)
Correct operation even at low temperatures

Areas of application

Perfect for decorative installations
Domestic applications
General illumination
Outdoor use in outdoor luminaires only (minimum IP65)

Product features

Professional LED lamps for line voltage
Not dimmable
Lifetime: up to 15,000 h
Beam angle: up to 300°
Lamp made of glass
Good quality of light; color rendering index R_a: ≥ 80; constant chromaticity

GTIN and Packaging information

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4058075267183	Folding box 1	64 mm x 64 mm x 131 mm	49.00 g	0.54 dm³
4058075506664	Shipping box 10	332 mm x 138 mm x 147 mm	637.00 g	6.73 dm³
4058075751156	Shipping box 10	332 mm x 138 mm x 147 mm	637.00 g	6.73 dm³
4099854259883	Shipping box 10	332 mm x 138 mm x 147 mm	637.00 g	6.73 dm³

Product images and graphics

Product Image, Diagonal, White BG
LED VALUE CLA 7W 230V FIL B22D JPG (1.49 MB)

Product Image, Upright, White BG
LED VALUE CLA 7W 230V FIL B22D JPG (1.25 MB)

Product line drawing with letters
Classic A B22d FIL SVG (12.58 KB)

Energy label
EL-4058075267183-AC243 55 PDF (21.43 KB)

Energy label
EL-4058075267183-AC324 13 PDF (21.44 KB)

Photometric and lighting design files

IES file (IES)
LED CLASSIC A 4 W FIL non-dim 2700K IES (20.92 KB)

LDT file (Eulumdat)
LV CLA 4W 827 230V FIL B22D LDT (11.8 KB)

LDC typ polar
LV CLA 4W 827 230V FIL B22D SVG (592.01 KB)
