Product description |
---|
UVC DULUX S 5W G23 |
UVC DULUX S 7W G23 |
UVC DULUX S 9W G23 |
UVC DULUX S 11W G23 |
Nominal wattage | 11 W |
Nominal voltage | 91 V |
Nominal current | 155 mA |
Operating frequency | 50…60 Hz |
Mains frequency | 50…60 Hz |
Radiated power 200…280 nm (UVC) | 3.2 W |
Starting time | 30.0 s |
Overall length | 236.50 mm |
Length | 236.50 mm |
Length with base excl. base pins/connection | 213.5 mm |
Outer bulb [PICOS] | T11 |
Diameter | 11.00 mm |
Tube diameter | 11,0 mm |
Product weight | 29.5 g |
Ambient temperature range | +10…+50 °C |
Nominal lamp life time | 9500 h |
Base (standard designation) | G23 |
Mercury content | 1.6 mg |
Dimmable | No |
Burning position | Any |
Standards | CE |
Photobiological safety group acc. to EN62778 | RG3 |
Order reference | UVC DULUX S 11W |
Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
---|---|---|---|---|
4058075595781 | Folding box 1 |
23 mm x 36 mm x 242 mm | 54.00 g | 0.20 dm³ |
4058075595798 | Shipping box 10 |
190 mm x 54 mm x 257 mm | 504.00 g | 2.64 dm³ |
EAN | STK number |
---|---|
4058075595781 | 4933218 |
